Sequence_Map< T, ID, H > Class Template Reference

A Sequence_Map is a collection of related sequences of T objects. Sequences supported by a Sequence_Map can not contain optional members. The template argument, H is the name of a class object with an operator()(T) that produces and integer value which is a 'hash' of T. More...

#include <sequence_map.h>

Inheritance diagram for Sequence_Map< T, ID, H >:
Inheritance graph
[legend]
Collaboration diagram for Sequence_Map< T, ID, H >:
Collaboration graph
[legend]

List of all members.

Classes

struct  H1
struct  node
class  search
 A 'search' is a context for comparing an arbitrary sequence with those stored in the Sequence_Map. The idea of course is to determine whether or not a given sequence exactly matches one found in the map -- and also what the ID of that sequence is. A search is a kind of iterator that scans through the structure of the Sequence_Map. You have to call operator++ to get to the next location in the sequence. If you want to know if you are sitting at the end of the sequence, call finished. A search does not exactly model an iterator so it has no comparison functions, and the Sequence_Map has no begin or end methods. More...
class  sequence
 A sequence is a handle object that lets you create patterns in the tree You construct a sequence object given a Sequence_Map object. You then add members to the sequence. When you are done, you call the complete() function to see if this is a valid (complete) sequence or if you have mistakenly create a subsequence of an existing sequence. More...

Public Types

typedef hash_list< node *, ID, H1id_map_type
 storage type for complete sequence ID's.
typedef hash_list< T, node *, H > rest_type
 description of the rest of a given sequence assuming you are already in the sequence somewhere
typedef Sequence_Map< T, ID, H > self
 helper typedef that refers to the sequence map

Public Member Functions

template<class Iterator >
bool find (Iterator first, Iterator last, ID *id)
 Compare a range to see if is an exact match for an named pattern. If so, return true and the id of the matched pattern. If not return false, and don't change the id.
bool find (T const *first, size_t count, ID *id)
 Compare an array to see if it is complete sequence and get the sequence id.
 Sequence_Map ()
 Construct an empty sequence map.
 ~Sequence_Map ()
 The _destructor_! What will they think of next!

Private Member Functions

void destroy_tree ()
 private method that recursively frees up all memory used by the tree.

Private Attributes

id_map_type ids_
 list of all sequences in this sequence map
rest_type root_
 the list of T's that begin sequences

Friends

class search
class sequence

Detailed Description

template<class T, class ID, class H = Hasher<T>>
class cxxtls::Sequence_Map< T, ID, H >

A Sequence_Map is a collection of related sequences of T objects. Sequences supported by a Sequence_Map can not contain optional members. The template argument, H is the name of a class object with an operator()(T) that produces and integer value which is a 'hash' of T.

Each Sequence has a given name, specified by the ID class. One purpose of a sequence map is to provide you with a mechanism for analyzing sequences of T's to determine which named sequence it maches, if any. That is, you define a bunch of sequence of T's. You identify each sequence by giving it a unique ID. You can then compare any random sequence to see if it has a match in the Sequence_Map and if so, what is its ID.

You can also use the Sequence_Map to aid in parsing random sequences and bomb out early when you realize that you don't have a valid sequence. A Sequence_Map can help you implement syntax directed parsing. For example, suppose you are parsing output from a computer program and you want to detect and act upon certain strings but not all. The emacs gud-mode does this. A sequence map can help with this. Another use is in parsing function keys from terminals. Sometimes unix buffering causes function key sequences to be split across multiple 'read()' calls. You can't guarantee that you'll get all 5 characters in the f12 sequence, for example, in a single read() operation. Yet you don't want to hard read for 5 characters all the time because the key sequences are often shorter than 5 characters -- typically they are 1, 3, or 5 characters long, but not always.

The design for Sequence_Map is roughly based on a Huffman coding scheme -- although Huffman would probably spin in his grave if he saw how big and complex this mechanism is -- he was interested in compressing bit patterns for com networks. Here we are interested in a simple, universally applicable interface that provides often need tools for simple pattern recognition.

The algorithmic complexity of a Sequence_Map is as follows: Once the sequences are inserted into the map, searching the map for a given item in the sequence is O(1). That is, if have N items in your test sequence, it will take roughly O(N) steps to validate whether or not it is a good sequence -- and get its ID value. Inserting a new sequence into the map is approximately O(N) where N is the length of the sequence.

Here's how you use a sequence map:

To perform a search, you ask the Sequence_Map for an iterator like object which contains the context of a search. You can then iterate over your test sequence, one item at a time, and ask the context object if this is a member of any valid sequence in the sequence map. It will give you the following information:

Here is an example:

     struct H { int operator() (int t) { return t; } };  // int hasher

     typedef Sequence_Map<char,int,H> SEQMAP;
                                       // or accept the default hasher which is
                                       // Hasher<char>
     typedef SM::sequence             SEQUENCE;
     typedef SM::search               SEARCH;

     SEQMAP tree;

       SEQUENCE s1(tree, 1); // fred
                s1 += 'f';   s1 += 'r';   s1 += 'e' ;   s1 += 'd';
                if(! s1.complete() )
                   error("subsequence of longer sequence");

       SEQUENCE s2(tree, 2); // frat
                s2 += 'f';   s2 += 'r';   s2 += 'a' ;   s2 += 't';
                if(! s2.complete() )
                  error("subsequence of longer sequence");

       // tree now has 2 sequences in it.

       int  id;
       bool found = tree.find("frat", 4, &id);  // id is 2, found is true

       char const *search="fred";

       char const *scan = search;

       SEARCH c(tree);

       while(*scan != 0 && c(*scan))
       {
          ++scan;
          ++c;
       }

       if(*scan == 0 && c.finished(&id) )
       {
         // id will have 1 in it because the context, c, indicates
         // that the subsequence has been completed.
       }

Notes:

Definition at line 48 of file sequence_map.h.


Member Typedef Documentation

typedef hash_list<node*,ID,H1> id_map_type

storage type for complete sequence ID's.

Definition at line 216 of file sequence_map.h.

typedef hash_list<T,node*,H> rest_type

description of the rest of a given sequence assuming you are already in the sequence somewhere

data structure representing the rest of a all possible sequences after the current sub-sequence of T's.

Definition at line 185 of file sequence_map.h.

typedef Sequence_Map<T,ID,H> self

helper typedef that refers to the sequence map

Definition at line 183 of file sequence_map.h.


Constructor & Destructor Documentation

Sequence_Map (  )

Construct an empty sequence map.

Definition at line 218 of file sequence_map.h.

~Sequence_Map (  )

The _destructor_! What will they think of next!

Definition at line 222 of file sequence_map.h.


Member Function Documentation

void destroy_tree (  )  [private]

private method that recursively frees up all memory used by the tree.

Definition at line 511 of file sequence_map.h.

Here is the caller graph for this function:

bool find ( Iterator  first,
Iterator  last,
ID *  id
)

Compare a range to see if is an exact match for an named pattern. If so, return true and the id of the matched pattern. If not return false, and don't change the id.

Definition at line 255 of file sequence_map.h.

bool find ( T const *  first,
size_t  count,
ID *  id
)

Compare an array to see if it is complete sequence and get the sequence id.

Definition at line 226 of file sequence_map.h.


Friends And Related Function Documentation

friend class search [friend]

Definition at line 506 of file sequence_map.h.

friend class sequence [friend]

Definition at line 505 of file sequence_map.h.


Member Data Documentation

id_map_type ids_ [private]

list of all sequences in this sequence map

Definition at line 509 of file sequence_map.h.

rest_type root_ [private]

the list of T's that begin sequences

Definition at line 508 of file sequence_map.h.


The documentation for this class was generated from the following file:
