SymbolInfo Struct Reference

A description of a symbol as extracted by the cpptagdb.exe program. The description includes the type of the symbol, its full namespace name, its member name, the file and line where it is defined, and the kind of symbol it is: function, variable, namespace, etc. More...

#include <cpptagdb.h>

Collaboration diagram for SymbolInfo:
Collaboration graph
[legend]

List of all members.

Public Types

typedef std::multimap
< std::string, SymbolInfo
Children
typedef Children::const_iterator const_iterator
typedef Children::iterator iterator
enum  Type {
  Function,
  Variable,
  Class,
  Enum,
  Enumeration,
  Typedef,
  Namespace,
  FileScope,
  Used,
  Define,
  unknownType
}

Public Member Functions

std::string annotatedName (bool member=false) const
 return the member name with annotations
Type computeTypeId (std::string const &typeName)
 Update the typeId_ member appropriately based on the name of the symbol type identifier read from the .tagpp file.
void output (std::ostream &s, std::string indent) const
 Output this SymbolInfo object to a stream and include all its children indented underneath it. A start indentation string should be provided.
 SymbolInfo (std::string const &symbol, std::string const &member, std::string const &type, std::string const &file, int line)
 SymbolInfo ()
char typeChar () const
 return a 1 character type id for this member

Public Attributes

Children children_
 nested direct submembers of this symbol, assuming it is a class, struct, union, or namespace
std::string file_
 name of the file defining the symbol
std::string fullname_
 full symbol name: namespace::class::member
int line_
 line within file_ where the symbol is defined
std::string member_
 member name only: member
std::string type_
 cpptagdb.exe supplied type string
Type typeId_
 integer "type" of the symbol

Friends

std::ostream & operator<< (std::ostream &s, SymbolInfo const &me)
 ostreams.

Detailed Description

A description of a symbol as extracted by the cpptagdb.exe program. The description includes the type of the symbol, its full namespace name, its member name, the file and line where it is defined, and the kind of symbol it is: function, variable, namespace, etc.

Definition at line 42 of file cpptagdb.h.


Member Typedef Documentation

typedef std::multimap<std::string, SymbolInfo> Children

Definition at line 90 of file cpptagdb.h.

Definition at line 96 of file cpptagdb.h.

Definition at line 95 of file cpptagdb.h.


Member Enumeration Documentation

enum Type
Enumerator:
Function
Variable
Class
Enum
Enumeration
Typedef
Namespace
FileScope
Used
Define
unknownType

Definition at line 48 of file cpptagdb.h.


Constructor & Destructor Documentation

SymbolInfo (  )

Definition at line 70 of file cpptagdb.h.

SymbolInfo ( std::string const &  symbol,
std::string const &  member,
std::string const &  type,
std::string const &  file,
int  line
)

Definition at line 75 of file cpptagdb.h.


Member Function Documentation

std::string annotatedName ( bool  member = false  )  const

return the member name with annotations

Definition at line 160 of file cpptagdb.cxx.

Here is the caller graph for this function:

SymbolInfo::Type computeTypeId ( std::string const &  typeName  )

Update the typeId_ member appropriately based on the name of the symbol type identifier read from the .tagpp file.

Definition at line 74 of file cpptagdb.cxx.

void output ( std::ostream &  s,
std::string  indent
) const

Output this SymbolInfo object to a stream and include all its children indented underneath it. A start indentation string should be provided.

Definition at line 44 of file cpptagdb.cxx.

Here is the call graph for this function:

char typeChar (  )  const

return a 1 character type id for this member

Definition at line 135 of file cpptagdb.cxx.


Friends And Related Function Documentation

std::ostream& operator<< ( std::ostream &  s,
SymbolInfo const &  me
) [friend]

ostreams.

Returns:
the specified stream
Parameters:
s The ostream stream on which data will be written
me The SymbolInfo object to write to the stream.
Parameters:
me Global free functioon to print SymbolInfo objects to

Definition at line 103 of file cpptagdb.h.


Member Data Documentation

nested direct submembers of this symbol, assuming it is a class, struct, union, or namespace

Definition at line 92 of file cpptagdb.h.

std::string file_

name of the file defining the symbol

Definition at line 66 of file cpptagdb.h.

std::string fullname_

full symbol name: namespace::class::member

Definition at line 63 of file cpptagdb.h.

int line_

line within file_ where the symbol is defined

Definition at line 67 of file cpptagdb.h.

std::string member_

member name only: member

Definition at line 64 of file cpptagdb.h.

std::string type_

cpptagdb.exe supplied type string

Definition at line 65 of file cpptagdb.h.

integer "type" of the symbol

Definition at line 68 of file cpptagdb.h.


The documentation for this struct was generated from the following files:
