CursorWindow Class Reference

Before directly using this class, you should consider reading text_windows. More...

#include <cursorwindow.h>

Inheritance diagram for CursorWindow:

[legend]

Collaboration diagram for CursorWindow:

[legend]

List of all members.

Classes
class	Dialog
	A Dialog is a list of fields which which will be displayed in a viewport and the user can edit them. Users of a Dialog initalize the list of fields, each of which must be a Dialog::Element. They then let the user edit the fields. After editing is complete, the caller iterates over the fields to see what changed. More...
class	FileSelector
struct	input_event
	An input_event is _any_ kind of input from the user, including keys, screen resizes, etc. If NoKey is the type, then the event should be ignored. More...
class	Message
	A Message object is a simpler version of a Dialog. It does not allow the user to make any selections -- it just presents the user with a scrolloing list of lines of test. When the user presses enter, the message goes away. More...
struct	resize_handler
	A resize_handler gets invoked if the user resizes the window. But only if you have specified the resize handler to use by calling the set_resize_handler() method. If you don't make such a call, the window size change event will be reported by the read_input() function. If you do make the setting, you will not receive any ResizeKey events. If you are using viewports, the resize_handler's job is mainly to enforce your viewport resize policy. That is, you use this function to scale the viewports after a resize. If you are not using viewports, this function's job will be to repaint the window correctly. If you are using viewports, the resizing event will automatically invoke their repaint methods after first invoking your resize_handler. See the file lib/cursorwindow.c and look for function resize_viewports() to see what a resize_handler has to do. Note that you can't use that code directly. If you are using a resize_handler of your own construction, you should maintain your own list of viewports over which can iterate. More...
struct	row_col
	A pair of integers representing a row and a column. More...
class	Selection
	A Selection object is a simpler version of a Dialog. It presents the user with a list of strings of which he/she is allowed to select exactly one -- or press the escape key to abort. To use a Selection object, do the following: More...
class	viewport
	Before directly using this class, you should consider reading text_windows. More...
class	Window
	This class holds the real CursorWindow datastructures. It is hidden from view because its inclusion is unnecessary and because curses might be included which adds all kinds of annoying macros into your compilation stream. More...
Public Types
typedef OstreamableBuffer < CursorWindow, char, std::char_traits< char > >	buf_type
typedef char	char_type
enum	edit_function_names { func_unknown, func_up, func_down, func_left, func_right, func_ic, func_dc, func_home, func_end, func_prior, func_next, func_dc_prev, func_tab, func_btab, func_top, func_bottom, func_esc, func_enter, func_data, func_clreol, func_nextwd, func_prevwd, func_upword, func_dnword, func_undo, func_find, func_findnxt, func_findprv, func_repl, func_replnext, func_help, func_mark, func_dl, func_db, func_cb, func_wb, func_paste, func_goto, func_matching, func_dw, func_join, func_insline, func_to_edit, func_reread, func_switch, func_insfile, user_function_0 = 0x100 }
	Symbolic names for the normal text edit functions you might need to perform in a dialog window. Associated with a CursorWindow there is a mapping between key values (integers) and edit function enumeraion values. You can add your own functions to the window's edit function map -- but dialog handler won't use them for anything. To add your own functions, use numeric identifiers bigger than 'user_function_0'. There can be only intepretation of a given curses key value, but more than one key may map to the same edit function. More...
typedef traits_type::int_type	int_type
enum	key_names { first_function_key = 0x100, key_f1, key_f2, key_f3, key_f4, key_f5, key_f6, key_f7, key_f8, key_f9, key_f10, key_f11, key_f12, key_up, key_down, key_left, key_right, key_home, key_end, key_prior, key_next, key_ic, key_dc, key_bs, key_btab, key_sf1, key_sf2, key_sf3, key_sf4, key_sf5, key_sf6, key_sf7, key_sf8, key_sf9, key_sf10, key_sf11, key_sf12, key_sup, key_sdown, key_sleft, key_sright, key_shome, key_send, key_sprior, key_snext, key_sic, key_sdc, last_function_key }
	the names of function keys More...
typedef traits_type::off_type	off_type
typedef traits_type::pos_type	pos_type
enum	text_attributes { normal, reversed, underlined, blinking, bold, reverse_ul, reverse_bold, rev_ul_bold, bold_ul }
	Names for text attribute values. Note that they are mutually exclusive. More...
typedef std::char_traits< char >	traits_type
Public Member Functions
void	beep ()
	Produce an audible alarm.
void	box (int width, int height, bool filled, std::string title)
	Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.
void	box (int width, int height, bool filled, char const *title=0)
	Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.
void	box (int width, int height, bool filled, char const *title_string, unsigned length)
	Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.
void	clear_error ()
	Clear out the current error flag. Doesn't delete the string.
void	close ()
	Close the cursor window if it is open. Repaint the terminal screen with the saved contents if possible. Note that this does not damage any data structures -- it just closes the window and sets the flag. See resize_viewports() below.
row_col	curpos () const
	Get the current cursor position.
	CursorWindow ()
	Construct a cursor window but do not open it.
char const *	error () const
	Get a string representation of the most recent error if any. If no error has occurred, then null is returned. All methods first clear the error condition and set it only if there is an error.
void	fill_to_eol (char c=' ')
	Fill the rest of the current line, starting at the current cursor position, with a specified character -- defaulting to space.
void	fill_to_eos (char c=' ')
	Fill the rest of the current screen, starting at the current cursor position, with a specified character -- defaulting to space.
int	get_viewports (std::list< viewport > *viewports)
	Get a list of the currently extant viewports. Returns the count of viewports as well. The viewports returned are not the owner of the physical screen are valid ONLY until the next creation or deletion of a viewport.
void	needs_resized ()
	Called to force a complete repaint of the window.
std::auto_ptr< viewport >	new_viewport (viewport::repaint_handler *, viewport::position p=viewport::tiled)
	Create a new viewport. The default position descriptor is 'tiled'. See CursorWindow::viewport for details.
bool	open ()
	Attempt to open the cursor window -- return true on failure. If possible, save the current terminal screen contents. Note that this only opens the curses terminal window, it does not affect any data structures. See resize_viewports() below.
void	ostreamable_helper (char c)
	Helper function used by base class, Ostreamable, to actually perform io when you use syntax of the form:
input_event	read_input ()
	Attempt to read an input event. If wait is true, then wait indefinitely for such an event. If wait is false, wait about 1/10 of a second before return a NoKey event if there are no keys available. Note that this call also flushes any pending output to the screen so that you can see it before pressing any keys. See CursorWindow:: refresh() or viewport::refresh(). If the screen is resized, you may or may not receive an input_event -- based on whether a resize handler has been registered with the window.
void	refresh ()
	Flush pending output to the physical window. You call this when you have written stuff that doesn't get displayed because you are not calling read_event();.
void	repaint_all ()
	repaint everything.
void	resize_viewports (row_col const &old_size, row_col const &new_size)
	After you have manually closed and then reopened the terminal window usinging open() and close(), above, you should call resize_viewports() to re-layout the viepworts given any screen sized changes that occurred while the window was closed. This means that before closing, you should save the old screen size and then inquire it again after the open.
void	set_curpos (row_col rc)
	Move the cursor to the specified row and column.
void	set_curpos (int row, int col)
void	set_error (char const *)
	Set a new error string. The window does not take ownership of the error string.
void	set_resize_handler (resize_handler *)
	Instruct the CursorWindow to inform you of resize events by calling the operator method of a specified object rather than by returning a ResizeKey event when you call read_input.
void	set_text_attribute (int)
	Set the current text attribute.
row_col	size () const
	Get the width in columns and the height in rows of the actual window. Note that you cannot force this information but must live with the size you get.
int	text_attribute () const
	Get the current text attribute.
void	write (long c, int length=1)
	Write specified number of characters to the window in the default text attribute at the current cursor position. The default repeat count is 1.
void	write (std::string const &s, size_t length=1000000)
	Ditto.
void	write (char const *s)
	Write a string in the current text attributes at the current cursor position and move the cursor.
void	write (char const *, size_t length)
	Write a specified number of characters to the current cursor position and move the cursor.
	~CursorWindow ()
	Close the cursor window if it is open and then destruct it.
Static Public Member Functions
static std::string	func_name (int funcvalue)
	func_name is a function that returns a string value for each editor function in the above list. If you add your own, they will show up in this list ass 'user function' or some such thing.
static std::string	key_name (int keyvalue)
static std::string	select_file (std::string const &title, std::string const &dir_file_pattern, CursorWindow *w)
Static Public Attributes
static int	active_mark_att = CursorWindow::reverse_ul
	highlighted (selected) and marked lines
static int	active_title_att = CursorWindow::reverse_bold
	window title bar color
static int	bottom_att = CursorWindow::underlined
	bottom line of window highlights
static int	dialog_normal_att = CursorWindow::reverse_bold
	body of dialogs
static int	dialog_title_att = CursorWindow::rev_ul_bold
	title of dialogs
static std::map< int, int >	func
	func is the all important key to edit function map. See CursorWindow::edit_function_names commentary above. Whenever you press a key, the dialog popup() method uses this table to figure out if you are pressing a key which is bound to an edit function or just a plain old data key. Feel free to add new bindings if you want but be careful about removing existing bindings -- like the arrow keys!
static int	highlighted_att = CursorWindow::reversed
	highlighted (selected) but not marked
static int	inactive_mark_att = CursorWindow::bold
	marked but not highlighted (not selected)
static int	inactive_title_att = CursorWindow::bold_ul
	window title bar color
static int	normal_att = CursorWindow::normal
	normal text color
static std::string	word
	This string is nothing more than a list of characters which are valid word characters. Feel free to use this but be careful about elimnating letters, numbers, etc. See std::find_first_of() for a way to use this easily.
Private Member Functions
void	destroy_viewport (viewport *)
Private Attributes
Window *	window_
	the real implementation of window
Friends
class	SaveRestoreActiveWindow
class	viewport

Detailed Description

Before directly using this class, you should consider reading text_windows.

Note! when debugging programs using viewers, you must start the program first then attach to it using the debugger's 'attach processid' feature (or dbx -debug pdi feature). To debug the startup code, before the first keyboard input wait, set the environment variable, WAIT_FOR_DEBUGGER=1 before running the program. When the debugger attaches to the running process, you will be in a wait loop. Use the debugger's print mechanism or the assign mechanism to change the stop variable to 0. Then you can continue debugging as normal.

A CursorWindow is a rectangular grid of character cells which can be written into, read from, etc. It is used for interacting with human beings inside of xterm and console windows. A CursorWindow represents the entire xterm window or screen window on NT. If you want to use subwindows, use a CursorWindow::viewport. There are some builtin popup windows, and you can make more of your own using viewports. See CursorWindow::Dialog and CursorWindow::Selection.

A CursorWindow is a thin wrapper around some commonly used "curses" functions but does attempt to include them all. On NT, these functions are simulated as well. The kinds of textual decorations are limited.

You can only have one 'opened' cursor window at a time. If you need multiple CursorWindow objects, make sure only one is open at a time. The close() method and the open() method can be used to control this.

A CursorWindow should be viewed as a simplistic curses window -- it is by no means a sophisticated one. Here are the limitations:

1 foreground color and 1 background color defined for the whole window. It is possible to have reversed video characters, however.

individual character cells can be normal, reverse video, underlined, or blinking -- but not combinations thereof.

the upper left if 0,0.

writing into the window moves the cursor.

it is possible to read input from the user or to read character cell contents (or their attributes).

user input can contain normal characters, control characters, function keys, arrow keys, paging keys, screen resize flags, etc. It is not possible to detect modifier keys separately from the data keys they affect.

no alternate character sets are supported and the exact character set used is dependent on the platform and other factors not under program control.

As stated earlier, a CursorWindow represents an entire xterm screen -- or console window on NT. If you want to access subwindows, use a CursorWindow::viewport. See the nested class below.

CursorWindow has some important nested types:

    CursorWindow::viewport  -- A subwindow on top of a CursorWindow.
                                   If you need popup windows or window
                                   partitions, use these.

    CursorWindow::Dialog    -- An input form which can be popped
                                   up in a subwindow as needed to collect
                                   information from the user.  You can
                                   prompt for a Enter key press (Ok field),
                                   string inputs (String field), etc.

    CursorWindow::Selection -- An input form that lets the user select
                                   one of a list of items.

Associated with all cursor windows, there is a static map of keys to edit functions. See func -- which can be used as an array of key values which map to edit functions one might need in dealing with Dialog's. You can change the key mappings, add new ones, or use the map for your own purposes so long as you don't eliminate key mappings needed to fill out dialogs.

The Esc key has an annoying limitation. Whenever you press it, you must wait 1 second (1 whole second) before pressing any other keys or the Esc key will be lost. This is due to unix wierdness with key mappings. On NT, this wait is not needed.

There is also a std::string of word characters which. You can use the std::find_first_of() algorithm with this string to find words in strings.

On unix, the CursorWindow blocks and unblocks the following signals:

SIGALRM
SIGWINCH

Note also that if you use other signals it is possible that their occurrence will damage the screen layout though the curses calls to minimize this are used.

Note that on unix, with a true curses implementation of this functionality, the TERMINFO used will not be the default terminfo. Instead, a directory will be created in the user's home directory that contains both the source for the terminfo actually used and the compiled terminfo. In this way, you can edit the source and manually recompile the terminfo once it is automatically created for you. See "$HOME/.tools_home". This directory is created the first time you run any program using this curses interface. If you have trouble with the function keys, you can edit the xterm.info files and recompile using "/usr/bin/tic".

CursorWindow derives from Ostreamable -- which means that can be used as the target of operator<< for a small subset of the stream output operations. See Ostreamable for more details.

Definition at line 55 of file cursorwindow.h.

Member Typedef Documentation

typedef OstreamableBuffer<CursorWindow , char , std::char_traits<char > > buf_type [inherited]

Definition at line 102 of file streamable.h.

typedef char char_type [inherited]

Definition at line 96 of file streamable.h.

typedef traits_type::int_type int_type [inherited]

Definition at line 98 of file streamable.h.

typedef traits_type::off_type off_type [inherited]

Definition at line 99 of file streamable.h.

typedef traits_type::pos_type pos_type [inherited]

Definition at line 100 of file streamable.h.

typedef std::char_traits<char > traits_type [inherited]

Definition at line 97 of file streamable.h.

Member Enumeration Documentation

enum edit_function_names

Symbolic names for the normal text edit functions you might need to perform in a dialog window. Associated with a CursorWindow there is a mapping between key values (integers) and edit function enumeraion values. You can add your own functions to the window's edit function map -- but dialog handler won't use them for anything. To add your own functions, use numeric identifiers bigger than 'user_function_0'. There can be only intepretation of a given curses key value, but more than one key may map to the same edit function.

If you add new items to the edit_function_names list, make sure that you add mappings and names for those functions and in cursorwindow.c. See the CursorWindow::CursorWindow() for an example.

Feel free to stick application specific functions in the func[] map but don't create names for them here -- simply keep your own enum of the func names and make the first one have the value 'user_function_0' plus one.

Note also that if you wish to change the key bindings used by the dialog input mechanism, you need only modify CursorWindow::func to suit your liking.

Enumerator:

func_unknown	unknown function -- not a real function
func_up
func_down
func_left
func_right
func_ic	toggle insert character mode (rarely used, not implemented)
func_dc	delete the character under the cursor
func_home	move to left of line
func_end	move to right of line
func_prior	prev page -- page up
func_next	next page -- page down
func_dc_prev	delete char before current one (backspace key?)
func_tab	tab right
func_btab	back tab
func_top	top of this file or page being edited
func_bottom	bottom of this file or page being edited
func_esc	esc key pressed
func_enter	enter key pressed
func_data	normal data keys
func_clreol	clear to end of line
func_nextwd	move to next word
func_prevwd	move to prev word
func_upword	uppercase the current word and move to next
func_dnword	lowercase the current word and move to the next
func_undo	undo most recent change
func_find	find first
func_findnxt	find next
func_findprv	find prev
func_repl	replace first
func_replnext	replace n
func_help	get application specific help (default is F1 key)
func_mark	mark the current line
func_dl	delete line
func_db	delete block
func_cb	copy block
func_wb	write block to a file
func_paste	paste text into edit session
func_goto	prompt for a line number to goto
func_matching	find matching character -- used on {...}, [...], etc
func_dw	delete word
func_join	join this line with the next line
func_insline	insert blank line
func_to_edit	convert a view only session to an edit session
func_reread	verify that the disk copy of your edit session hasn't changed
func_switch	switch to alternate source (given your current edit file, find another)
func_insfile	insert a file above the current line
user_function_0

Definition at line 512 of file cursorwindow.h.

enum key_names

the names of function keys

Enumerator:

first_function_key
key_f1
key_f2
key_f3
key_f4
key_f5
key_f6
key_f7
key_f8
key_f9
key_f10
key_f11
key_f12
key_up
key_down
key_left
key_right
key_home
key_end
key_prior
key_next
key_ic
key_dc
key_bs
key_btab	next the shifted function keys -- which might be alt or ctrl function keys depending on the implementation -- but only one form is supported here -- and further shifted versions may (like the function keys themselves) may not be available
key_sf1
key_sf2
key_sf3
key_sf4
key_sf5
key_sf6
key_sf7
key_sf8
key_sf9
key_sf10
key_sf11
key_sf12
key_sup
key_sdown
key_sleft
key_sright
key_shome
key_send
key_sprior
key_snext
key_sic
key_sdc
last_function_key	don't use this for anything

Definition at line 486 of file cursorwindow.h.

enum text_attributes

Names for text attribute values. Note that they are mutually exclusive.

Enumerator:

normal	normal text with decoration
reversed	reversed video
underlined	normal text + underlining
blinking	normal text + blinking
bold	normal text + bold
reverse_ul	reverse video + underlined
reverse_bold	reverse video + bold
rev_ul_bold	reverse video + bold +underlined
bold_ul	bold + underlined

Definition at line 463 of file cursorwindow.h.

Constructor & Destructor Documentation

CursorWindow ( )

Construct a cursor window but do not open it.

Definition at line 917 of file cursorwindow.cxx.

~CursorWindow ( )

Close the cursor window if it is open and then destruct it.

Definition at line 1054 of file cursorwindow.cxx.

Here is the call graph for this function:

Member Function Documentation

void beep ( )

Produce an audible alarm.

Definition at line 1262 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void box	(	int	width,
		int	height,
		bool	filled,
		std::string	title
	)

Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.

If the filled flag is true, the box will be filled with blanks before the border is drawn.

Draw the title string, if specified, inside the top border of the box to serve as a title.

Definition at line 443 of file cursorwindow.h.

Here is the call graph for this function:

void box	(	int	width,
		int	height,
		bool	filled,
		char const *	title = `0`
	)

Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.

If the filled flag is true, the box will be filled with blanks before the border is drawn.

Draw the title string, if specified, inside the top border of the box to serve as a title.

Definition at line 428 of file cursorwindow.h.

Here is the call graph for this function:

void box	(	int	width,
		int	height,
		bool	filled,
		char const *	title_string,
		unsigned	length
	)

Draw a box starting at the current cursor position that is width columns wide and height columns tall (running down from the current cursor position.

If the filled flag is true, the box will be filled with blanks before the border is drawn.

If the string is not null, and the length is not 0, the string will be drawn inside the top border of the box to indicate that it is the 'title' of the box

Definition at line 1377 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void clear_error ( )

Clear out the current error flag. Doesn't delete the string.

Definition at line 234 of file cursorwindow.h.

Here is the call graph for this function:

void close ( )

Close the cursor window if it is open. Repaint the terminal screen with the saved contents if possible. Note that this does not damage any data structures -- it just closes the window and sets the flag. See resize_viewports() below.

Definition at line 1067 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

row_col curpos ( ) const

Get the current cursor position.

Definition at line 1237 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void destroy_viewport ( viewport * ) [private]

char const * error ( ) const

Get a string representation of the most recent error if any. If no error has occurred, then null is returned. All methods first clear the error condition and set it only if there is an error.

Definition at line 1093 of file cursorwindow.cxx.

void fill_to_eol ( char c = ' ' )

Fill the rest of the current line, starting at the current cursor position, with a specified character -- defaulting to space.

Definition at line 1346 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void fill_to_eos ( char c = ' ' )

Fill the rest of the current screen, starting at the current cursor position, with a specified character -- defaulting to space.

Definition at line 1356 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

string func_name ( int funcvalue ) [static]

func_name is a function that returns a string value for each editor function in the above list. If you add your own, they will show up in this list ass 'user function' or some such thing.

Definition at line 1000 of file cursorwindow.cxx.

Here is the caller graph for this function:

int get_viewports ( std::list< viewport > * viewports )

Get a list of the currently extant viewports. Returns the count of viewports as well. The viewports returned are not the owner of the physical screen are valid ONLY until the next creation or deletion of a viewport.

Definition at line 3743 of file cursorwindow.cxx.

string key_name ( int keyvalue ) [static]

Definition at line 1484 of file cursorwindow.cxx.

Here is the caller graph for this function:

void needs_resized ( )

Called to force a complete repaint of the window.

Definition at line 1108 of file cursorwindow.cxx.

std::auto_ptr< viewport > new_viewport	(	viewport::repaint_handler *	h,
		viewport::position	p = `viewport::tiled`
	)

Create a new viewport. The default position descriptor is 'tiled'. See CursorWindow::viewport for details.

Note that you can also create a viewport using viewport::vsplit() or viewport::hsplit(). These are meant for use with tiled windows which will be contiguous with one another -- although you can manually adjust the positions.

Creating a viewport does not activate it and does not draw it. Use the 'activate()' method of the viewport to do both.

Definition at line 1832 of file cursorwindow.cxx.

Here is the caller graph for this function:

bool open ( )

Attempt to open the cursor window -- return true on failure. If possible, save the current terminal screen contents. Note that this only opens the curses terminal window, it does not affect any data structures. See resize_viewports() below.

Definition at line 1076 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void ostreamable_helper ( char c )

Helper function used by base class, Ostreamable, to actually perform io when you use syntax of the form:

window << "stuff";

Definition at line 1603 of file cursorwindow.h.

Here is the call graph for this function:

CursorWindow::input_event read_input ( )

Attempt to read an input event. If wait is true, then wait indefinitely for such an event. If wait is false, wait about 1/10 of a second before return a NoKey event if there are no keys available. Note that this call also flushes any pending output to the screen so that you can see it before pressing any keys. See CursorWindow:: refresh() or viewport::refresh(). If the screen is resized, you may or may not receive an input_event -- based on whether a resize handler has been registered with the window.

Note that on unix, this function uses SIGALRM, and it does not save/restore the alarm timer value or signal handler.

Definition at line 1137 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void refresh ( )

Flush pending output to the physical window. You call this when you have written stuff that doesn't get displayed because you are not calling read_event();.

Definition at line 1117 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void repaint_all ( )

repaint everything.

Definition at line 5148 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void resize_viewports	(	row_col const &	old_size,
		row_col const &	new_size
	)

After you have manually closed and then reopened the terminal window usinging open() and close(), above, you should call resize_viewports() to re-layout the viepworts given any screen sized changes that occurred while the window was closed. This means that before closing, you should save the old screen size and then inquire it again after the open.

Definition at line 4384 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

string select_file	(	std::string const &	title,
		std::string const &	dir_file_pattern,
		CursorWindow *	w
	)			`[static]`

Definition at line 3641 of file cursorwindow.cxx.

Here is the call graph for this function:

void set_curpos ( row_col rc )

Move the cursor to the specified row and column.

Definition at line 1248 of file cursorwindow.cxx.

Here is the call graph for this function:

void set_curpos	(	int	row,
		int	col
	)

Parameters:

col

Move the cursor to the specified row and column.

Definition at line 359 of file cursorwindow.h.

Here is the caller graph for this function:

void set_error ( char const * s )

Set a new error string. The window does not take ownership of the error string.

Definition at line 1100 of file cursorwindow.cxx.

Here is the caller graph for this function:

void set_resize_handler ( CursorWindow::resize_handler * h )

Instruct the CursorWindow to inform you of resize events by calling the operator method of a specified object rather than by returning a ResizeKey event when you call read_input.

Definition at line 1533 of file cursorwindow.cxx.

Here is the caller graph for this function:

void set_text_attribute ( int a )

Set the current text attribute.

Definition at line 1476 of file cursorwindow.cxx.

Here is the caller graph for this function:

row_col size ( ) const

Get the width in columns and the height in rows of the actual window. Note that you cannot force this information but must live with the size you get.

Definition at line 1255 of file cursorwindow.cxx.

Here is the caller graph for this function:

int text_attribute ( ) const

Get the current text attribute.

Definition at line 1469 of file cursorwindow.cxx.

void write	(	long	c,
		int	length = `1`
	)

Write specified number of characters to the window in the default text attribute at the current cursor position. The default repeat count is 1.

Write a character multiple times in the current text attributes at the current cursor position and move the cursor.

Definition at line 1308 of file cursorwindow.cxx.

Here is the call graph for this function:

void write	(	std::string const &	s,
		size_t	length = `1000000`
	)

Ditto.

Definition at line 391 of file cursorwindow.h.

Here is the call graph for this function:

void write ( char const * s )

Write a string in the current text attributes at the current cursor position and move the cursor.

Definition at line 383 of file cursorwindow.h.

Here is the call graph for this function:

void write	(	char const *	s,
		size_t	length
	)

Write a specified number of characters to the current cursor position and move the cursor.

Write a string in the current text attributes at the current cursor position and move the cursor.

Definition at line 1269 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

Friends And Related Function Documentation

friend class SaveRestoreActiveWindow [friend]

Definition at line 176 of file cursorwindow.h.

friend class viewport [friend]

Definition at line 191 of file cursorwindow.h.

Member Data Documentation

int active_mark_att = CursorWindow::reverse_ul [static]

highlighted (selected) and marked lines

Definition at line 184 of file cursorwindow.h.

int active_title_att = CursorWindow::reverse_bold [static]

window title bar color

Definition at line 182 of file cursorwindow.h.

int bottom_att = CursorWindow::underlined [static]

bottom line of window highlights

Definition at line 186 of file cursorwindow.h.

int dialog_normal_att = CursorWindow::reverse_bold [static]

body of dialogs

Definition at line 188 of file cursorwindow.h.

int dialog_title_att = CursorWindow::rev_ul_bold [static]

title of dialogs

Definition at line 189 of file cursorwindow.h.

std::map< int, int > func [static]

func is the all important key to edit function map. See CursorWindow::edit_function_names commentary above. Whenever you press a key, the dialog popup() method uses this table to figure out if you are pressing a key which is bound to an edit function or just a plain old data key. Feel free to add new bindings if you want but be careful about removing existing bindings -- like the arrow keys!

Definition at line 592 of file cursorwindow.h.

int highlighted_att = CursorWindow::reversed [static]

highlighted (selected) but not marked

Definition at line 187 of file cursorwindow.h.

int inactive_mark_att = CursorWindow::bold [static]

marked but not highlighted (not selected)

Definition at line 185 of file cursorwindow.h.

int inactive_title_att = CursorWindow::bold_ul [static]

window title bar color

Definition at line 183 of file cursorwindow.h.

int normal_att = CursorWindow::normal [static]

normal text color

Definition at line 181 of file cursorwindow.h.

Window* window_ [private]

the real implementation of window

Definition at line 1628 of file cursorwindow.h.

string word [static]

This string is nothing more than a list of characters which are valid word characters. Feel free to use this but be careful about elimnating letters, numbers, etc. See std::find_first_of() for a way to use this easily.

Definition at line 602 of file cursorwindow.h.

The documentation for this class was generated from the following files:

include/cxxtls/cursorwindow.h
lib/cursorwindow.cxx

CursorWindow Class Reference

Classes

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Private Member Functions

Private Attributes

Friends

Detailed Description

Member Typedef Documentation

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
