Element Class Reference

An input element in a Dialog. This is an abstract base class from which you can derive -- although there are some builtins (Ok,string, etc). The popup() function will handle some keys and some will be sent to the element's handle_key method. The draw() method may be invoked multiples times within the popup() function call. More...

#include <cursorwindow.h>

Inheritance diagram for Element:

[legend]

Collaboration diagram for Element:

[legend]

List of all members.

Public Member Functions
virtual void	draw_input_area (viewport *v, bool highlighted)=0
	Draw the input area of this field in the specified viewport. The cursor will already be positioned for you. Do not draw more than 'input_width_' characters. If the highlighted flag is passed in, the field is active, otherwise it is not.
	Element (std::string const &name, std::string const &label, int width=0)
virtual void	handle_key (viewport *v, int key)=0
	Interpret keys passed to this field by popup() as the user wants to make changes. Only some keys get to the field -- data keys, and left and right arrow keys for example, but not up and down or paging keys.
virtual	~Element ()
Public Attributes
int	input_width_
std::string	label_
std::string	name_
std::string	value_
Protected Attributes
Dialog *	dialog_
Friends
class	Dialog

---

Detailed Description

An input element in a Dialog. This is an abstract base class from which you can derive -- although there are some builtins (Ok,string, etc). The popup() function will handle some keys and some will be sent to the element's handle_key method. The draw() method may be invoked multiples times within the popup() function call.


          To add Elements to a dialog, do this:

            Dialog d("title");

              d += new ElementType(initializer);
              d += new ElementType(initializer);
              d += new ElementType(initializer);

          To allow user's to edit, then do this:

              if(! d.popup() )
              {
                iterate over the elements in d and extract the
                names and updated values for your use.  use begin(),
                and end() to get iterators to the elements
              }

The popup() function draws the labels and the dialog title. The element is responsible for drawing its input area -- but not violate the input_width_ which may not be the same as what is specified during the element's construction.

the popup() function handles keyboard input and distributes some keys to the element's handle_key function: data keys and left and right arrows but no other keys -- except key_dc.

Definition at line 1126 of file cursorwindow.h.

---

Constructor & Destructor Documentation

Element	(	std::string const &	name,
		std::string const &	label,
		int	width = 0
	)

Definition at line 1178 of file cursorwindow.h.

virtual ~Element

(

)

[virtual]

Definition at line 1186 of file cursorwindow.h.

---

Member Function Documentation

virtual void draw_input_area	(	viewport *	v,
		bool	highlighted
	)			[pure virtual]

Draw the input area of this field in the specified viewport. The cursor will already be positioned for you. Do not draw more than 'input_width_' characters. If the highlighted flag is passed in, the field is active, otherwise it is not.

Implemented in Ok, and String.

Here is the caller graph for this function:

virtual void handle_key	(	viewport *	v,
		int	key
	)			[pure virtual]

Interpret keys passed to this field by popup() as the user wants to make changes. Only some keys get to the field -- data keys, and left and right arrow keys for example, but not up and down or paging keys.

Implemented in Ok, and String.

---

Friends And Related Function Documentation

friend class Dialog [friend]

Definition at line 1169 of file cursorwindow.h.

---

Member Data Documentation

Dialog* dialog_ [protected]

Definition at line 1166 of file cursorwindow.h.

int input_width_

Definition at line 1176 of file cursorwindow.h.

std::string label_

Definition at line 1174 of file cursorwindow.h.

std::string name_

Definition at line 1173 of file cursorwindow.h.

std::string value_

Definition at line 1175 of file cursorwindow.h.

---

The documentation for this class was generated from the following file:

• include/cxxtls/cursorwindow.h
