String Class Reference

A String is a dialog element that prompts the user for a character string -- providing a default value. Normal keyboard editing keys are active. The 'tab' key has special interpretation. It completes the string under the cursor. That is, if you press the tab key, the string under the cursor is treated as a partial file name fragment and you are presented with the valid completions for your selection. If there is only one valid selection, it is chosen for you automatically. More...

#include <cursorwindow.h>

Inheritance diagram for String:
Inheritance graph
[legend]
Collaboration diagram for String:
Collaboration graph
[legend]

List of all members.

Public Member Functions

bool compute_actual_width (viewport *v)
 Compute actual width of input area given window size limitations. The function return value indicates that the offset_ member changed -- this implies a need to repaint the text input region.
void draw_input_area (viewport *v, bool highlighted)
 paints [ ok ]
void handle_key (viewport *v, int key)
 ignores all keys
void handle_paging (viewport *v)
 Use horizontal paging if necessary to insure that the character in the string under col_ is actually visible.
void setColumn (int col)
 Set the current input column.
 String (std::string const &name, std::string const &label, std::string const &default_value, int input_width)

Public Attributes

int input_width_
std::string label_
std::string name_
std::string value_

Protected Attributes

Dialogdialog_
bool password_
 this is a password string -- dont' echo its contents

Private Attributes

int col_
 current input column (where cursor goes) (relative to the string, not the window.
int input_
 actual_input_col_ obtained by draw_input_area when ever it is invoked. This is the left most column where input of this string occurs in its dialog window.
int offset_
 from beginning of string to first displayed char -- ie the character displayed in the input_ col.
int width_
 ACTUAL input width given window size limitations.

Friends

class Dialog

Detailed Description

A String is a dialog element that prompts the user for a character string -- providing a default value. Normal keyboard editing keys are active. The 'tab' key has special interpretation. It completes the string under the cursor. That is, if you press the tab key, the string under the cursor is treated as a partial file name fragment and you are presented with the valid completions for your selection. If there is only one valid selection, it is chosen for you automatically.

In order for tab completion to work correctly, you will probably have to use Dialog::set_completion_directory() based on the 'current' directory you wish to present the user with. This can be obtained from the ViewerManager using ViewerManager::active_directory().

Definition at line 1241 of file cursorwindow.h.


Constructor & Destructor Documentation

String ( std::string const &  name,
std::string const &  label,
std::string const &  default_value,
int  input_width
)

< Construct a string field.

Definition at line 1277 of file cursorwindow.h.


Member Function Documentation

bool compute_actual_width ( viewport v  )

Compute actual width of input area given window size limitations. The function return value indicates that the offset_ member changed -- this implies a need to repaint the text input region.

Definition at line 2236 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void draw_input_area ( viewport v,
bool  highlighted
) [virtual]

paints [ ok ]

Implements Element.

Definition at line 2308 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void handle_key ( viewport v,
int  key
) [virtual]

ignores all keys

Implements Element.

Definition at line 2359 of file cursorwindow.cxx.

Here is the call graph for this function:

void handle_paging ( viewport v  )

Use horizontal paging if necessary to insure that the character in the string under col_ is actually visible.

Definition at line 2288 of file cursorwindow.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void setColumn ( int  col  )

Set the current input column.

Definition at line 2351 of file cursorwindow.cxx.

Here is the caller graph for this function:


Friends And Related Function Documentation

friend class Dialog [friend, inherited]

Definition at line 1169 of file cursorwindow.h.


Member Data Documentation

int col_ [private]

current input column (where cursor goes) (relative to the string, not the window.

Definition at line 1259 of file cursorwindow.h.

Dialog* dialog_ [protected, inherited]

Definition at line 1166 of file cursorwindow.h.

int input_ [private]

actual_input_col_ obtained by draw_input_area when ever it is invoked. This is the left most column where input of this string occurs in its dialog window.

Definition at line 1267 of file cursorwindow.h.

int input_width_ [inherited]

Definition at line 1176 of file cursorwindow.h.

std::string label_ [inherited]

Definition at line 1174 of file cursorwindow.h.

std::string name_ [inherited]

Definition at line 1173 of file cursorwindow.h.

int offset_ [private]

from beginning of string to first displayed char -- ie the character displayed in the input_ col.

Definition at line 1262 of file cursorwindow.h.

bool password_ [protected]

this is a password string -- dont' echo its contents

Definition at line 1273 of file cursorwindow.h.

std::string value_ [inherited]

Definition at line 1175 of file cursorwindow.h.

int width_ [private]

ACTUAL input width given window size limitations.

Definition at line 1265 of file cursorwindow.h.


The documentation for this class was generated from the following files:
