ListViewer Class Reference

A ListViewer is a simplified version of the generic Viewer interface. It only handles the viewing/editing of lists of strings. Each string is presented in vertical list form -- one string per line. More...

#include <viewer.h>

Inheritance diagram for ListViewer:

[legend]

Collaboration diagram for ListViewer:

[legend]

List of all members.

Classes
struct	policies
	An abstract base class definining the list of strings to to be displayed/edited and a command handler. The command handler must not do any displaying of its own. More...
Public Types
enum	cmd_constant { activate, deactivate, resize }
	values that will be passed to the function call operator method. More...
typedef CursorWindow::input_event	input_event
	typename alias
typedef std::list< std::string >	paste_buffer_type
	The data type of the paste buffer.
typedef CursorWindow::row_col	row_col
	typename alias
typedef CursorWindow::viewport	viewport
	Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.
Public Member Functions
std::string const &	application_name () const
	For ListViewers, the application name command is just passed through to the policy object for implementation.
void	commitPasteBuffer () const
	write the paste buffer to the os clipboard.
std::string	description () const
	For ListViewers, the description() method is just passed through to the policy object for implementation.
virtual bool	fetchAllLines (std::list< std::string > &output)
void	fetchPasteBuffer ()
	read the paste buffer from the os clipboard
int	find_string (size_t index)
	Repeats the find operation started by find_string(index,vm), above. The user will not be prompted for a new string -- the old one will be used for this new search.
int	find_string (size_t index, ViewerManager *vm)
	Prompt the user for a string which will then be used to initiate a search starting at the current line. The cursor will be left on the line, below the current line, which contains the string -- if a match was found.
bool	handle_event (input_event const e, viewport vp)
	(not virtual)
virtual void	help ()
	See ListViewer::policies::help_text for comments.
virtual bool	is_dirty () const
int	line_attribute (bool selected, size_t index, bool is_bottom)
	Compute text attributes of lines given some information about the line.
	ListViewer (policies comtable, ViewerManager man)
ViewerManager *	manager ()
void	operator() (viewport *vp, int cmd)
	Handle screen repaint policies (not virtual).
void	output_row_text (viewport *vp, int i)
	output one row of the viewed text
paste_buffer_type *	paste_buffer ()
	Get a pointer to the viewer manager's paste buffer.
void	repaint (viewport *vp)
	wrapper around the function call operator that makes it easier to invoke a repaint.
virtual void	set_row_col_hint (size_t line, size_t column, bool repaint=false)
	The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.
Protected Attributes
ViewerManager *	manager_
Private Attributes
bool	active_
std::auto_ptr< policies >	com_
size_t	cur_row_
size_t	display_top_
int	first_row_
std::string	search_string_

Detailed Description

A ListViewer is a simplified version of the generic Viewer interface. It only handles the viewing/editing of lists of strings. Each string is presented in vertical list form -- one string per line.

A ListViewer is not meant for handling wide strings like files might have. It is meant rather for the display of strings where horizontal scrolling isn't really necessary. That is, you might need to compress your strings to fit in the space available rather than relying on horizontal scroll bars. See DirectoryViewer's implementation. The directory viewer chooses the text to be displayed based on the amount of horizontal space available -- and it provides a command, 'i', which toggles the display of certain less important text.

To construct a ListViewer, you must supply a ListViewer::policies object which will provide the list of strings and also a command handler for events not processed by the ListViewer itself. That is, the ListViewer will handle display, paging, etc. All other commands must be processed -- one string at a time.

Note that the policies object will be deleted by the ListViewer upon its destruction!

Here's how to use a ListViewer:

derive from ListViewer::policies to create a list of strings to display and implement the handle_event method and the resize_handler method (if needed -- its optional).

user operator new to create an object of that type and use that value to construct a ListViewer object.

give the ListViewer to the ViewerManager -- or animate it yourself using direction in Viewer. (strongly advised against)

Note that there are two ways to give a ListViewer to the viewer manager. One way is to manually create the ListViewer and use one of

    ViewerManager::add
    ViewerManager::vsplit
    ViewerManager::hsplit

The other way is to let the ViewerManager create the viewer in the first place. To accomplish this, you use the ViewerManager::add_app function to provide the viewer manager with a function that will create the ListViewer for you. That is, you write a function that will prompt the user for parameters to the constructor to your ListViewer, then you give that function to the viewer manager. The viewer manager will then be able to present the user with a list of 'application' functions and let him choose which function to call -- and thus which kind of application viewer to create. A nice way to create this function is to make it a static member of the policies class, and you could also make the application name a static member of policies as well. In this way you don't have any extraneous free functions and variables laying around.

Definition at line 230 of file viewer.h.

Member Typedef Documentation

typedef CursorWindow::input_event input_event [inherited]

typename alias

Definition at line 192 of file viewer.h.

typedef std::list<std::string> paste_buffer_type [inherited]

The data type of the paste buffer.

Definition at line 194 of file viewer.h.

typedef CursorWindow::row_col row_col [inherited]

typename alias

Definition at line 191 of file viewer.h.

typedef CursorWindow::viewport viewport [inherited]

Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

typename alias

Definition at line 190 of file viewer.h.

Member Enumeration Documentation

enum cmd_constant [inherited]

values that will be passed to the function call operator method.

Enumerator:

activate	means you have been activated
deactivate	some other viewport has taken focus
resize	only the size has changed

Definition at line 793 of file cursorwindow.h.

Constructor & Destructor Documentation

ListViewer	(	policies *	comtable,
		ViewerManager *	man
	)

Contruct a ListViewer given a pointer to a ListViewer::policies object and a pointer to the ViewerManager which will own this list viewer. The ViewerManager will orchestrate the destruction of this list viewer and that destruction will also cause the destruction of the policies object. Do not manually delete either.

Definition at line 401 of file viewer.h.

Member Function Documentation

std::string const& application_name ( ) const [virtual]

For ListViewers, the application name command is just passed through to the policy object for implementation.

Implements Viewer.

Definition at line 458 of file viewer.h.

void commitPasteBuffer ( ) const [inherited]

write the paste buffer to the os clipboard.

Definition at line 625 of file viewer.cxx.

Here is the caller graph for this function:

std::string description ( ) const [virtual]

For ListViewers, the description() method is just passed through to the policy object for implementation.

Implements Viewer.

Definition at line 465 of file viewer.h.

bool fetchAllLines ( std::list< std::string > & output ) [virtual]

See also:: cxxtls::Viewer::fetchAllLines().

Reimplemented from Viewer.

Definition at line 712 of file viewer.cxx.

void fetchPasteBuffer ( ) [inherited]

read the paste buffer from the os clipboard

Definition at line 661 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

int find_string ( size_t index )

Repeats the find operation started by find_string(index,vm), above. The user will not be prompted for a new string -- the old one will be used for this new search.

Definition at line 552 of file viewer.cxx.

Here is the call graph for this function:

int find_string	(	size_t	index,
		ViewerManager *	vm
	)

Prompt the user for a string which will then be used to initiate a search starting at the current line. The cursor will be left on the line, below the current line, which contains the string -- if a match was found.

Definition at line 528 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool handle_event	(	CursorWindow::input_event const *	e,
		CursorWindow::viewport *	vp
	)			`[virtual]`

(not virtual)

Implements Viewer.

Definition at line 238 of file viewer.cxx.

Here is the call graph for this function:

void help ( ) [virtual]

See ListViewer::policies::help_text for comments.

Reimplemented from Viewer.

Definition at line 590 of file viewer.cxx.

Here is the call graph for this function:

bool is_dirty ( ) const [virtual, inherited]

Reimplemented in TableViewer.

Definition at line 611 of file viewer.cxx.

Here is the caller graph for this function:

int line_attribute	(	bool	selected,
		size_t	index,
		bool	is_bottom
	)

Compute text attributes of lines given some information about the line.

determine text color/attributes given info about how the text will be used.

Definition at line 50 of file viewer.cxx.

Here is the caller graph for this function:

ViewerManager* manager ( ) [inherited]

Definition at line 126 of file viewer.h.

Here is the caller graph for this function:

void operator()	(	CursorWindow::viewport *	vp,
		int	cmd
	)			`[virtual]`

Handle screen repaint policies (not virtual).

Implements Viewer.

Definition at line 107 of file viewer.cxx.

Here is the call graph for this function:

void output_row_text	(	viewport *	vp,
		int	i
	)

output one row of the viewed text

Definition at line 429 of file viewer.h.

Here is the caller graph for this function:

Viewer::paste_buffer_type * paste_buffer ( ) [inherited]

Get a pointer to the viewer manager's paste buffer.

Definition at line 601 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void repaint ( viewport * vp )

wrapper around the function call operator that makes it easier to invoke a repaint.

Definition at line 423 of file viewer.h.

Here is the caller graph for this function:

virtual void set_row_col_hint	(	size_t	line,
		size_t	column,
		bool	repaint = `false`
	)			`[virtual, inherited]`

The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.

Again, obedience to this function is entirely optional and most viewers will ignore it.

The line and column numbers are 0 base! Contrary to normal user's expectations, so account for this in any input calculations you make.

Definition at line 202 of file viewer.h.

Here is the caller graph for this function:

Member Data Documentation

bool active_ [private]

Definition at line 395 of file viewer.h.

std::auto_ptr<policies> com_ [private]

Definition at line 389 of file viewer.h.

size_t cur_row_ [private]

Definition at line 392 of file viewer.h.

size_t display_top_ [private]

Definition at line 391 of file viewer.h.

int first_row_ [private]

Definition at line 393 of file viewer.h.

ViewerManager* manager_ [protected, inherited]

Definition at line 117 of file viewer.h.

std::string search_string_ [private]

Definition at line 397 of file viewer.h.

The documentation for this class was generated from the following files:

include/cxxtls/viewer.h
lib/viewer.cxx
