TableViewer Class Reference

A TableViewer is a kind of viewer that shows rows and columns and allows the user to move around within the table. The TableViewer class is meant primarily to be derived from. It handles the basics of table editing without doing anything really useful. You should derive from a TableViewer and implement various methods as needed to do something useful. More...

#include <tableviewer.h>

Inheritance diagram for TableViewer:
Inheritance graph
[legend]
Collaboration diagram for TableViewer:
Collaboration graph
[legend]

List of all members.

Classes

struct  CellInfo
struct  ColumnInfo
struct  CursorInfo
 Set the "edit cell" for the table in world coordinates. If the cursor is currently visible and not already at the specified location it will be moved. More...
struct  FieldAttributes
struct  RowInfo

Public Types

enum  cmd_constant {
  activate,
  deactivate,
  resize
}


values that will be passed to the function call operator method.

More...
typedef CursorWindow::input_event input_event
 typename alias
typedef std::vector
< std::vector< CellInfo > > 		LayoutType
typedef std::list< std::string > paste_buffer_type
 The data type of the paste buffer.
typedef CursorWindow::row_col row_col
 typename alias
typedef CursorWindow::viewport viewport
 Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

Public Member Functions

bool active () const
 Return the current "is window active" flag.
void addColumnData (std::string const &text)
void addColumnHeader (std::string const &title, size_t width, FieldAttributes const &a, bool border)
 Add a column to the column header table.
void addColumnHeader (std::string const &title, size_t width, bool border)
 Add a column to the column header table.
void addRow (std::string const &title, size_t height, bool bottomBorder, bool bold=false, bool editable=true, bool executable=true)
virtual std::string const & application_name () const
 Return the application name.
CellInfo * cellInfo (size_t row, size_t col)
 return a null or a modifiable pointer to the specified cell information.
CellInfo const * cellInfo (size_t row, size_t col) const
 return a null or a const pointer to the specified cell information.
void clear ()
 Discard all rows and columns.
size_t cols () const
 return count of table columns
size_t columnWidth (size_t column) const
 Consult the layout_ and the cols_ tables to determine with maximum of the column header and the widest cell in that column. Does not include gutters.
void commitPasteBuffer () const
 write the paste buffer to the os clipboard.
CursorInfo cursorInfo () const
 Return the current cursor information.
virtual std::string description () const
 Return a description of the application.
virtual bool fetchAllLines (std::list< std::string > &output)
 An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.
void fetchPasteBuffer ()
 read the paste buffer from the os clipboard
virtual bool handle_event (CursorWindow::input_event const *e, CursorWindow::viewport *vp)
 Handle keystrokes and other events.
virtual void help ()
 Display help about this application.
void hideCursor (CursorWindow::viewport *vp)
 If cursor is visible, repaint it to remove its highlighting. Also, terminate any edit state operations (if any).
virtual bool is_dirty () const
 Return true if the application has modifications.
size_t longestRowTitle () const
 returns the number of chars in longest title
ViewerManager * manager ()
bool mixed_case () const
 Return the state of the mixed-case-find flag.
void moveDown (CursorWindow::viewport *vp)
 Move the cursor down one row. Normally bound to the down arrow key.
void moveLeft (CursorWindow::viewport *vp)
 Move the cursor left one column. Normally bound to the left arrow key.
void moveRight (CursorWindow::viewport *vp)
 Move the cursor right one column. Normally bound to the right arrow key.
void moveUp (CursorWindow::viewport *vp)
 Move the cursor up one row. Normally bound to the up arrow key.
virtual void operator() (CursorWindow::viewport *vp, int cmd)
 Handle screen repaint commands.
size_t originCol () const
 top left corner column
size_t originRow () const
 top left corner row
void pageBottom (CursorWindow::viewport *vp)
 Move the cursor to the last valid rows, and keep the column the same.
void pageDown (CursorWindow::viewport *vp)
 Move the cursor down one page. Keep the column the same.
void pageEnd (CursorWindow::viewport *vp)
 Move the cursor to maxrow,maxcol Keep the column the same.
void pageHome (CursorWindow::viewport *vp)
 Move the cursor to 0,0.
void pageLeft (CursorWindow::viewport *vp)
 Move the cursor left one page. Keep the column the same.
void pageRight (CursorWindow::viewport *vp)
 Move the cursor right one page. Keep the column the same.
void pageTop (CursorWindow::viewport *vp)
 Move the cursor to the first row in the table. keep the column the same.
void pageUp (CursorWindow::viewport *vp)
 Move the cursor up one page. Keep the column the same.
void paintCell (CursorWindow::viewport *vp, size_t vpRow, size_t vpCol, size_t tbRow, size_t tbCol, bool highlight=false, bool editCursor=true)
 Paint the specified cell at the specified viewport location. No validity checking is done. The most recently painted viewport is used.
virtual void paintCursor (CursorWindow::viewport *)
 If the cursor is marked for display, draw it on the screen.
paste_buffer_type * paste_buffer ()
 Get a pointer to the viewer manager's paste buffer.
virtual void repaintTitle (CursorWindow::viewport *vp)
 Repaint the title (presumably after it has changed).
RowInfo const & rowInfo (size_t row) const
 get a copy of a specified row titles, etc.
size_t rows () const
 return count of table rows
void set_data_dirty (bool f)
 Set the 'unsaved modifications' flag.
virtual void set_row_col_hint (size_t line, size_t column, bool repaint=false)
 The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.
void setColInfo (size_t col, std::string const &title, size_t width, bool border, bool bold, bool edit)
 Set the column header information.
void setColInfo (size_t col, std::string const &title, size_t width, bool border)
 Set the column header information.
void setCursorInfo (CursorWindow::viewport *vp, CursorInfo const &i)
 Set the cursor information given a CursorInfo structure.
virtual void setCursorInfo (CursorWindow::viewport *vp, size_t worldRow, size_t worldCol, bool displayed=true)
void setDisplayTitles (bool flag)
 Set the flag that controls the permanancy of the displaying of the row and column titles.
void setOrigin (size_t row, size_t col)
 Set the upper left corner column in the world world of the layout_ no the screen coordinate world.
void setRowInfo (size_t row, RowInfo const &r)
 Set the titles and other row specific information givin a row.
void setRowInfo (size_t row, std::string const &title, size_t height, bool border, bool bold, bool edit)
 Set the row header information.
void setRowInfo (size_t row, std::string const &title, size_t height, bool border)
 Set the row header information.
void setRowsAndColumns (size_t rows, size_t cols)
 Set the maximum number of rows and columns in the layout. Adding or deleting as necessary to make it happen.
void showCursor (CursorWindow::viewport *vp)
 If the cursor is not already displayed, repaint it to indicate highlighting for edit.
 TableViewer (ViewerManager *vm)
void triggerLayoutRecompute ()
 implement a copy constructor!
virtual ~TableViewer ()

Protected Member Functions

void checkLayoutRecompute ()
void deleteRow (CursorWindow::viewport *vp)
 Erase the current row.
void findFirst (CursorWindow::viewport *vp)
 Prompt the user for find string parameter and search for that string from the current edit point.
virtual bool findNext (CursorWindow::viewport *vp, bool first)
 Search for the current search_text_ from the current cell to the end of the table. Update the screen to reflect the new cursor position.
void forceRelayout ()
 mark the table layout for recomputation at some later point in time
void insertRowAbove (CursorWindow::viewport *vp, RowInfo const &info)
 Insert new row above the current row.
void insertRowBelow (CursorWindow::viewport *vp, RowInfo const &info)
 Insert new row below the current row.
virtual void paintField (CursorWindow::viewport *vp, size_t vpRow, size_t vpCol, CellInfo const *cell, size_t cellRow, size_t vpColumns, bool editCursor)
 Paint the text of a cell's row and any trailing blanks needed to pad the string's width to vpColumns.
void positionTextInputPointer (CursorWindow::viewport *vp)
void setTextInputPointer (size_t vpRow, size_t vpCol)
 Set the screen location where text cursor goes.

Protected Attributes

std::vector< ColumnInfo > cols_
std::vector< size_t > colWidths_
bool is_regex_
 If true, use regular expression searches.
LayoutType layout_
ViewerManager * manager_
bool match_words_
 If true, use word searches.
bool mixed_case_
 If true, use case insensitive searches.
size_t pageHeight_
size_t pageWidth_
std::vector< RowInfo > rows_
std::string search_text_
 Text to search for ////////////////////////////////////////////////////////////////////////////////////.

Private Member Functions

void recomputeLayout ()
 Regenerate the world coords in layout_.

Private Attributes

bool active_
size_t cursorCol_
bool cursorDisplayed_
size_t cursorRow_
bool dataDirty_
CursorWindow::row_col displayOrigin_
bool displayTitles_
bool layoutDirty_
size_t originCol_
size_t originRow_
CursorWindow::row_col textInputPointer_
ViewerManager * viewerManager_

Detailed Description

A TableViewer is a kind of viewer that shows rows and columns and allows the user to move around within the table. The TableViewer class is meant primarily to be derived from. It handles the basics of table editing without doing anything really useful. You should derive from a TableViewer and implement various methods as needed to do something useful.

Note that the TableEditor class allows the user to edit table columns and rows.

Instructions for creating a useful table viewer sub-class:

<blockquote>

Definition at line 8 of file tableviewer.h.

Member Typedef Documentation

typedef CursorWindow::input_event input_event [inherited]

typename alias

Definition at line 192 of file viewer.h.

typedef std::vector< std::vector< CellInfo > > LayoutType

Definition at line 624 of file tableviewer.h.

typedef std::list<std::string> paste_buffer_type [inherited]

The data type of the paste buffer.

Definition at line 194 of file viewer.h.

typedef CursorWindow::row_col row_col [inherited]

typename alias

Definition at line 191 of file viewer.h.

typedef CursorWindow::viewport viewport [inherited]

Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

typename alias

Definition at line 190 of file viewer.h.

Member Enumeration Documentation

enum cmd_constant [inherited]

values that will be passed to the function call operator method.

Enumerator:
activate

means you have been activated

deactivate

some other viewport has taken focus

resize

only the size has changed

Definition at line 793 of file cursorwindow.h.

Constructor & Destructor Documentation

TableViewer ( ViewerManager *  vm  )

Definition at line 37 of file tableviewer.h.

~TableViewer (  )  [virtual]

Definition at line 44 of file tableviewer.cxx.

Member Function Documentation

bool active (  )  const

Return the current "is window active" flag.

A given window is active if it has text focus, otherwise it is not.

Definition at line 615 of file tableviewer.h.

Here is the caller graph for this function:

void addColumnData ( std::string const &  text  )

Definition at line 387 of file tableviewer.h.

Here is the call graph for this function:

Here is the caller graph for this function:

void addColumnHeader ( std::string const &  title,
size_t  width,
FieldAttributes const &  a,
bool  border
)

Add a column to the column header table.

Parameters:
title defines the title for the row
width defines the number of screen columns to for this world column
a defines the field attributes
border defines the left border drawing option

Definition at line 371 of file tableviewer.h.

void addColumnHeader ( std::string const &  title,
size_t  width,
bool  border
)

Add a column to the column header table.

Parameters:
title defines the title for the row
width defines the number of screen columns to for this world column
border defines the left border drawing option

Definition at line 360 of file tableviewer.h.

Here is the caller graph for this function:

void addRow ( std::string const &  title,
size_t  height,
bool  bottomBorder,
bool  bold = false,
bool  editable = true,
bool  executable = true
)

Definition at line 407 of file tableviewer.h.

Here is the caller graph for this function:

string const & application_name (  )  const [virtual]

Return the application name.

Implements Viewer.

Reimplemented in CsvViewer, and ScriptTableViewer.

Definition at line 416 of file tableviewer.cxx.

Here is the caller graph for this function:

TableViewer::CellInfo * cellInfo ( size_t  row,
size_t  col
)

return a null or a modifiable pointer to the specified cell information.

Parameters:
row defines the zero based row number of interest
col defines the zero based column number of interest
Returns:
a modifiable pointer to the desired cell or null if the cell does not exist.

Definition at line 551 of file tableviewer.cxx.

Here is the call graph for this function:

TableViewer::CellInfo const * cellInfo ( size_t  row,
size_t  col
) const

return a null or a const pointer to the specified cell information.

Parameters:
row defines the zero based row number of interest
col defines the zero based column number of interest
Returns:
a const pointer to the desired cell or null if the cell does not exist.

Definition at line 543 of file tableviewer.cxx.

Here is the caller graph for this function:

void checkLayoutRecompute (  )  [protected]

Definition at line 741 of file tableviewer.h.

Here is the call graph for this function:

Here is the caller graph for this function:

void clear (  )

Discard all rows and columns.

Definition at line 1151 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

size_t cols (  )  const

return count of table columns

Definition at line 254 of file tableviewer.h.

Here is the caller graph for this function:

size_t columnWidth ( size_t  column  )  const

Consult the layout_ and the cols_ tables to determine with maximum of the column header and the widest cell in that column. Does not include gutters.

Definition at line 510 of file tableviewer.cxx.

Here is the caller graph for this function:

void commitPasteBuffer (  )  const [inherited]

write the paste buffer to the os clipboard.

Definition at line 625 of file viewer.cxx.

Here is the caller graph for this function:

CursorInfo cursorInfo (  )  const

Return the current cursor information.

Definition at line 491 of file tableviewer.h.

Here is the caller graph for this function:

void deleteRow ( CursorWindow::viewport *  vp  )  [protected]

Erase the current row.

Parameters:
vp the viewport to draw in -- though none is none

Definition at line 1242 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

string description (  )  const [virtual]

Return a description of the application.

Implements Viewer.

Reimplemented in CsvViewer, and ScriptTableViewer.

Definition at line 425 of file tableviewer.cxx.

bool fetchAllLines ( std::list< std::string > &  output  )  [virtual, inherited]

An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.

Warning:
This is an optional feature, many viewers do not support it.
Parameters:
[out] output The location to store all the lines from this viewer.
Returns:
true to indicate that the data was extracted and false to indicate that this viewer does not support this feature.

Reimplemented in ListViewer.

Definition at line 705 of file viewer.cxx.

Here is the caller graph for this function:

void fetchPasteBuffer (  )  [inherited]

read the paste buffer from the os clipboard

Definition at line 661 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void findFirst ( CursorWindow::viewport *  vp  )  [protected]

Prompt the user for find string parameter and search for that string from the current edit point.

Definition at line 1257 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool findNext ( CursorWindow::viewport *  vp,
bool  first
) [protected, virtual]

Search for the current search_text_ from the current cell to the end of the table. Update the screen to reflect the new cursor position.

Parameters:
vp The viewport in which to draw
first True if the is first time this string has been used for the search (and thus the current cell should be searched).
Returns:
true to indicate that the search text was found and that the the screen has been updated.

Definition at line 1373 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void forceRelayout (  )  [protected]

mark the table layout for recomputation at some later point in time

Definition at line 718 of file tableviewer.h.

Here is the caller graph for this function:

bool handle_event ( CursorWindow::input_event const *  e,
CursorWindow::viewport *  vp
) [virtual]

Handle keystrokes and other events.

Implements Viewer.

Reimplemented in CsvViewer, ScriptTableViewer, and TableEditor.

Definition at line 337 of file tableviewer.cxx.

Here is the call graph for this function:

void help (  )  [virtual]

Display help about this application.

Reimplemented from Viewer.

Reimplemented in CsvViewer, and ScriptTableViewer.

Definition at line 433 of file tableviewer.cxx.

void hideCursor ( CursorWindow::viewport *  vp  )

If cursor is visible, repaint it to remove its highlighting. Also, terminate any edit state operations (if any).

Definition at line 667 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void insertRowAbove ( CursorWindow::viewport *  vp,
RowInfo const &  info
) [protected]

Insert new row above the current row.

Parameters:
vp the viewport to draw in
info the title of the current row

Definition at line 1172 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void insertRowBelow ( CursorWindow::viewport *  vp,
RowInfo const &  info
) [protected]

Insert new row below the current row.

Parameters:
vp the viewport to draw in
info the title of the current row

Definition at line 1194 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool is_dirty (  )  const [virtual]

Return true if the application has modifications.

Reimplemented from Viewer.

Definition at line 441 of file tableviewer.cxx.

Here is the caller graph for this function:

size_t longestRowTitle (  )  const

returns the number of chars in longest title

Definition at line 449 of file tableviewer.cxx.

Here is the caller graph for this function:

ViewerManager* manager (  )  [inherited]

Definition at line 126 of file viewer.h.

Here is the caller graph for this function:

bool mixed_case (  )  const

Return the state of the mixed-case-find flag.

Definition at line 621 of file tableviewer.h.

Here is the caller graph for this function:

void moveDown ( CursorWindow::viewport *  vp  )

Move the cursor down one row. Normally bound to the down arrow key.

Definition at line 896 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveLeft ( CursorWindow::viewport *  vp  )

Move the cursor left one column. Normally bound to the left arrow key.

Definition at line 930 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveRight ( CursorWindow::viewport *  vp  )

Move the cursor right one column. Normally bound to the right arrow key.

Definition at line 954 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveUp ( CursorWindow::viewport *  vp  )

Move the cursor up one row. Normally bound to the up arrow key.

Definition at line 869 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void operator() ( CursorWindow::viewport *  vp,
int  cmd
) [virtual]

Handle screen repaint commands.

Implements Viewer.

Definition at line 63 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

size_t originCol (  )  const

top left corner column

Definition at line 257 of file tableviewer.h.

Here is the caller graph for this function:

size_t originRow (  )  const

top left corner row

Definition at line 256 of file tableviewer.h.

Here is the caller graph for this function:

void pageBottom ( CursorWindow::viewport *  vp  )

Move the cursor to the last valid rows, and keep the column the same.

Normally bound to the control B key.

Definition at line 1121 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageDown ( CursorWindow::viewport *  vp  )

Move the cursor down one page. Keep the column the same.

Normally bound to the PageDown or Next key.

Definition at line 1001 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageEnd ( CursorWindow::viewport *  vp  )

Move the cursor to maxrow,maxcol Keep the column the same.

Normally bound to the end key

Definition at line 1110 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageHome ( CursorWindow::viewport *  vp  )

Move the cursor to 0,0.

Normally bound to the Home key

Definition at line 1101 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageLeft ( CursorWindow::viewport *  vp  )

Move the cursor left one page. Keep the column the same.

Normally bound to the shift-Tab key.

Definition at line 1069 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageRight ( CursorWindow::viewport *  vp  )

Move the cursor right one page. Keep the column the same.

Normally bound to the tab key.

Definition at line 1034 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageTop ( CursorWindow::viewport *  vp  )

Move the cursor to the first row in the table. keep the column the same.

Normally bound to the control B key.

Definition at line 1138 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageUp ( CursorWindow::viewport *  vp  )

Move the cursor up one page. Keep the column the same.

Normally bound to the PageUp or Prior key.

Definition at line 980 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintCell ( CursorWindow::viewport *  vp,
size_t  vpRow,
size_t  vpCol,
size_t  tbRow,
size_t  tbCol,
bool  highlight = false,
bool  editCursor = true
)

Paint the specified cell at the specified viewport location. No validity checking is done. The most recently painted viewport is used.

Parameters:
vp the viewport to draw in
vpRow the viewport row
vpCol the column
tbRow table row
tbCol the table column
highlight flag indicating highlighted display
editCursor flag indicating the cursor should be left in edit poisiton

Definition at line 785 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintCursor ( CursorWindow::viewport *  vp  )  [virtual]

If the cursor is marked for display, draw it on the screen.

The function is virtual so that derived classes can hook into the repaint functionality so they can position the edit cursor.

Parameters:
vp is the viewport to positiont he cursor into

Definition at line 684 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintField ( CursorWindow::viewport *  vp,
size_t  vpRow,
size_t  vpCol,
TableViewer::CellInfo const *  cell,
size_t  cellRow,
size_t  vpColumns,
bool  editCursor
) [protected, virtual]

Paint the text of a cell's row and any trailing blanks needed to pad the string's width to vpColumns.

Parameters:
vpRow The upper left row where display is to start
vpCol The upper left col where display is to start
cell A pointer to the layout_ location being painted.
cellRow The row within the cell to paint.
vpColumns The width of the field.
editCursor Indicates the cursor should be left in feild edit position (if true).

This function exists to be superseeded by derived classes.

Note that the leading gutter will have been painted and the text attributes set before this function is called.

If editCursor is false, then the cursor will be left at the end end of the field. This flag is ignored if the field is not editable and the cursor will end up at the end.

Reimplemented in TableEditor.

Definition at line 834 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

Viewer::paste_buffer_type * paste_buffer (  )  [inherited]

Get a pointer to the viewer manager's paste buffer.

Definition at line 601 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void positionTextInputPointer ( CursorWindow::viewport *  vp  )  [protected]

Definition at line 1164 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void recomputeLayout (  )  [private]

Regenerate the world coords in layout_.

Definition at line 579 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void repaintTitle ( CursorWindow::viewport *  vp  )  [virtual]

Repaint the title (presumably after it has changed).

Parameters:
vp The viewport where this table is drawn.

By default, this function prints the application name, but derived classes may wish to superseed this behavior.

Reimplemented in ScriptTableViewer.

Definition at line 48 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

RowInfo const& rowInfo ( size_t  row  )  const

get a copy of a specified row titles, etc.

Parameters:
row The row to modify
Returns:
The specified row's information.

Definition at line 414 of file tableviewer.h.

Here is the caller graph for this function:

size_t rows (  )  const

return count of table rows

Definition at line 253 of file tableviewer.h.

Here is the caller graph for this function:

void set_data_dirty ( bool  f  )

Set the 'unsaved modifications' flag.

Parameters:
f defines the status of the dirty flag.

See the function is_dirty().

Definition at line 608 of file tableviewer.h.

Here is the caller graph for this function:

virtual void set_row_col_hint ( size_t  line,
size_t  column,
bool  repaint = false
) [virtual, inherited]

The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.

Again, obedience to this function is entirely optional and most viewers will ignore it.

The line and column numbers are 0 base! Contrary to normal user's expectations, so account for this in any input calculations you make.

Definition at line 202 of file viewer.h.

Here is the caller graph for this function:

void setColInfo ( size_t  col,
std::string const &  title,
size_t  width,
bool  border,
bool  bold,
bool  edit
)

Set the column header information.

Parameters:
col defines the col number of interest (world col, not screen col)
title defines the title for the row
width defines the number of screen columns to for this world column
border defines the left border drawing option
bold defines the bold display attribute for this column
edit defines the editable flag for this colum

Definition at line 339 of file tableviewer.h.

void setColInfo ( size_t  col,
std::string const &  title,
size_t  width,
bool  border
)

Set the column header information.

Parameters:
col defines the col number of interest (world col, not screen col)
title defines the title for the row
width defines the number of screen columns to for this world column
border defines the left border drawing option

Definition at line 322 of file tableviewer.h.

Here is the caller graph for this function:

void setCursorInfo ( CursorWindow::viewport *  vp,
CursorInfo const &  i
)

Set the cursor information given a CursorInfo structure.

Definition at line 495 of file tableviewer.h.

Here is the call graph for this function:

void setCursorInfo ( CursorWindow::viewport *  vp,
size_t  worldRow,
size_t  worldCol,
bool  displayed = true
) [virtual]

Reimplemented in CsvViewer, and TableEditor.

Definition at line 647 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void setDisplayTitles ( bool  flag  )

Set the flag that controls the permanancy of the displaying of the row and column titles.

Parameters:
flag if true, means that the titles should always be displayed.

Definition at line 259 of file tableviewer.h.

void setOrigin ( size_t  row,
size_t  col
)

Set the upper left corner column in the world world of the layout_ no the screen coordinate world.

Parameters:
row is the row in the virtual world
col is the column in hte virtual world

Definition at line 443 of file tableviewer.h.

Here is the caller graph for this function:

void setRowInfo ( size_t  row,
RowInfo const &  r
)

Set the titles and other row specific information givin a row.

Parameters:
row The row to modify
r The RowInfo to change

Definition at line 420 of file tableviewer.h.

void setRowInfo ( size_t  row,
std::string const &  title,
size_t  height,
bool  border,
bool  bold,
bool  edit
)

Set the row header information.

Parameters:
row defines the row number of interest (world row, not screen row)
title defines the title for the row
height defines the number of screen rows to reserve vertically for "row"
border defines the bottom border drawing option
bold defines the bold drawing flag for the row
edit defines the editable flag for this row

Definition at line 300 of file tableviewer.h.

void setRowInfo ( size_t  row,
std::string const &  title,
size_t  height,
bool  border
)

Set the row header information.

Parameters:
row defines the row number of interest (world row, not screen row)
title defines the title for the row
height defines the number of screen rows to reserve vertically for "row"
border defines the bottom border drawing option

Definition at line 283 of file tableviewer.h.

Here is the caller graph for this function:

void setRowsAndColumns ( size_t  rows,
size_t  cols
)

Set the maximum number of rows and columns in the layout. Adding or deleting as necessary to make it happen.

Parameters:
rows is the exact number of rows to establish
cols is the exact number of cols to establish.

Definition at line 492 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void setTextInputPointer ( size_t  vpRow,
size_t  vpCol
) [protected]

Set the screen location where text cursor goes.

Parameters:
vpRow is the viewport relative row
vpCol is the viewport relative column

Definition at line 707 of file tableviewer.h.

Here is the caller graph for this function:

void showCursor ( CursorWindow::viewport *  vp  )

If the cursor is not already displayed, repaint it to indicate highlighting for edit.

Definition at line 676 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void triggerLayoutRecompute (  )

implement a copy constructor!

Called by field editing functions to inform the table repaint mechanism, operator()(), that the column sizes need to be recomputed.

Definition at line 63 of file tableviewer.h.

Here is the caller graph for this function:

Member Data Documentation

bool active_ [private]

Definition at line 636 of file tableviewer.h.

std::vector<ColumnInfo> cols_ [protected]

Definition at line 666 of file tableviewer.h.

std::vector<size_t> colWidths_ [protected]

Definition at line 660 of file tableviewer.h.

size_t cursorCol_ [private]

Definition at line 640 of file tableviewer.h.

bool cursorDisplayed_ [private]

Definition at line 641 of file tableviewer.h.

size_t cursorRow_ [private]

Definition at line 639 of file tableviewer.h.

bool dataDirty_ [private]

Definition at line 650 of file tableviewer.h.

CursorWindow::row_col displayOrigin_ [private]

Definition at line 644 of file tableviewer.h.

bool displayTitles_ [private]

Definition at line 635 of file tableviewer.h.

bool is_regex_ [protected]

If true, use regular expression searches.

Definition at line 672 of file tableviewer.h.

LayoutType layout_ [protected]

Definition at line 663 of file tableviewer.h.

bool layoutDirty_ [private]

Definition at line 637 of file tableviewer.h.

ViewerManager* manager_ [protected, inherited]

Definition at line 117 of file viewer.h.

bool match_words_ [protected]

If true, use word searches.

Definition at line 673 of file tableviewer.h.

bool mixed_case_ [protected]

If true, use case insensitive searches.

Definition at line 671 of file tableviewer.h.

size_t originCol_ [private]

Definition at line 633 of file tableviewer.h.

size_t originRow_ [private]

Definition at line 632 of file tableviewer.h.

size_t pageHeight_ [protected]

Definition at line 658 of file tableviewer.h.

size_t pageWidth_ [protected]

Definition at line 657 of file tableviewer.h.

std::vector<RowInfo> rows_ [protected]

Definition at line 665 of file tableviewer.h.

std::string search_text_ [protected]

Text to search for ////////////////////////////////////////////////////////////////////////////////////.

Definition at line 674 of file tableviewer.h.

CursorWindow::row_col textInputPointer_ [private]

Definition at line 648 of file tableviewer.h.

ViewerManager* viewerManager_ [private]

Definition at line 646 of file tableviewer.h.

The documentation for this class was generated from the following files:
Generated on Wed Feb 29 22:57:17 2012 for CXXUtilities by  doxygen 1.6.3
