CsvViewer Class Reference

A Comma Separated Values file viewer. More...

#include <csvviewer.h>

Inheritance diagram for CsvViewer:

[legend]

Collaboration diagram for CsvViewer:

[legend]

List of all members.

Public Types
enum	cmd_constant {   activate,   deactivate,   resize }
	values that will be passed to the function call operator method. More...
typedef CursorWindow::input_event	input_event
	typename alias
typedef std::vector < std::vector< CellInfo > >	LayoutType
typedef std::list< std::string >	paste_buffer_type
	The data type of the paste buffer.
typedef CursorWindow::row_col	row_col
	typename alias
typedef CursorWindow::viewport	viewport
	Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.
Public Member Functions
bool	active () const
	Return the current "is window active" flag.
void	addColumnData (std::string const &text)
void	addColumnHeader (std::string const &title, size_t width, FieldAttributes const &a, bool border)
	Add a column to the column header table.
void	addColumnHeader (std::string const &title, size_t width, bool border)
	Add a column to the column header table.
void	addRow (std::string const &title, size_t height, bool bottomBorder, bool bold=false, bool editable=true, bool executable=true)
virtual std::string const &	application_name () const
	Return the application name.
CellInfo *	cellInfo (size_t row, size_t col)
	return a null or a modifiable pointer to the specified cell information.
CellInfo const *	cellInfo (size_t row, size_t col) const
	return a null or a const pointer to the specified cell information.
void	clear ()
	Discard all rows and columns.
size_t	cols () const
	return count of table columns
size_t	columnWidth (size_t column) const
	Consult the layout_ and the cols_ tables to determine with maximum of the column header and the widest cell in that column. Does not include gutters.
void	commitPasteBuffer () const
	write the paste buffer to the os clipboard.
	CsvViewer (ViewerManager *vm, std::string const &filename, int delimChar=',')
	Construct a CsvViewer and open its file and read it into memory. The lines in the file are assumed to be delimited by the specified delimiter character. This constructor assumes that the first line of the file contains the names of the columns rather than the data for a row of text. The column headers must be delimited as well.
CursorInfo	cursorInfo () const
	Return the current cursor information.
virtual std::string	description () const
	Return a description of the application.
std::string const &	error () const
	Returns the most recent file i/o error.
virtual bool	fetchAllLines (std::list< std::string > &output)
	An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.
void	fetchPasteBuffer ()
	read the paste buffer from the os clipboard
void	hideCursor (CursorWindow::viewport *vp)
	If cursor is visible, repaint it to remove its highlighting. Also, terminate any edit state operations (if any).
virtual bool	is_dirty () const
	Return true if the application has modifications.
size_t	longestRowTitle () const
	returns the number of chars in longest title
ViewerManager *	manager ()
bool	mixed_case () const
	Return the state of the mixed-case-find flag.
void	moveDown (CursorWindow::viewport *vp)
	Move the cursor down one row. Normally bound to the down arrow key.
void	moveLeft (CursorWindow::viewport *vp)
	Move the cursor left one column. Normally bound to the left arrow key.
void	moveRight (CursorWindow::viewport *vp)
	Move the cursor right one column. Normally bound to the right arrow key.
void	moveUp (CursorWindow::viewport *vp)
	Move the cursor up one row. Normally bound to the up arrow key.
bool	ok () const
	Return true if no file read errors have occurred. See error() for details of any error.
virtual void	operator() (CursorWindow::viewport *vp, int cmd)
	Handle screen repaint commands.
size_t	originCol () const
	top left corner column
size_t	originRow () const
	top left corner row
void	pageBottom (CursorWindow::viewport *vp)
	Move the cursor to the last valid rows, and keep the column the same.
void	pageDown (CursorWindow::viewport *vp)
	Move the cursor down one page. Keep the column the same.
void	pageEnd (CursorWindow::viewport *vp)
	Move the cursor to maxrow,maxcol Keep the column the same.
void	pageHome (CursorWindow::viewport *vp)
	Move the cursor to 0,0.
void	pageLeft (CursorWindow::viewport *vp)
	Move the cursor left one page. Keep the column the same.
void	pageRight (CursorWindow::viewport *vp)
	Move the cursor right one page. Keep the column the same.
void	pageTop (CursorWindow::viewport *vp)
	Move the cursor to the first row in the table. keep the column the same.
void	pageUp (CursorWindow::viewport *vp)
	Move the cursor up one page. Keep the column the same.
void	paintCell (CursorWindow::viewport *vp, size_t vpRow, size_t vpCol, size_t tbRow, size_t tbCol, bool highlight=false, bool editCursor=true)
	Paint the specified cell at the specified viewport location. No validity checking is done. The most recently painted viewport is used.
virtual void	paintCursor (CursorWindow::viewport *)
	If the cursor is marked for display, draw it on the screen.
paste_buffer_type *	paste_buffer ()
	Get a pointer to the viewer manager's paste buffer.
virtual void	repaintTitle (CursorWindow::viewport *vp)
	Repaint the title (presumably after it has changed).
RowInfo const &	rowInfo (size_t row) const
	get a copy of a specified row titles, etc.
size_t	rows () const
	return count of table rows
void	set_data_dirty (bool f)
	Set the 'unsaved modifications' flag.
virtual void	set_row_col_hint (size_t line, size_t column, bool repaint=false)
	The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.
void	setColInfo (size_t col, std::string const &title, size_t width, bool border, bool bold, bool edit)
	Set the column header information.
void	setColInfo (size_t col, std::string const &title, size_t width, bool border)
	Set the column header information.
void	setCursorInfo (CursorWindow::viewport *vp, CursorInfo const &i)
	Set the cursor information given a CursorInfo structure.
void	setDisplayTitles (bool flag)
	Set the flag that controls the permanancy of the displaying of the row and column titles.
void	setOrigin (size_t row, size_t col)
	Set the upper left corner column in the world world of the layout_ no the screen coordinate world.
void	setRowInfo (size_t row, RowInfo const &r)
	Set the titles and other row specific information givin a row.
void	setRowInfo (size_t row, std::string const &title, size_t height, bool border, bool bold, bool edit)
	Set the row header information.
void	setRowInfo (size_t row, std::string const &title, size_t height, bool border)
	Set the row header information.
void	setRowsAndColumns (size_t rows, size_t cols)
	Set the maximum number of rows and columns in the layout. Adding or deleting as necessary to make it happen.
void	showCursor (CursorWindow::viewport *vp)
	If the cursor is not already displayed, repaint it to indicate highlighting for edit.
void	triggerLayoutRecompute ()
	implement a copy constructor!
virtual	~CsvViewer ()
Static Public Member Functions
static Viewer *	app (ViewerManager *vm, std::string &fullname)
	Application "hook" function for the CsvViewer class. Use it as a parameter to add_app, like this:
Protected Member Functions
void	checkLayoutRecompute ()
void	deleteRow (CursorWindow::viewport *vp)
	Erase the current row.
CellInfo *	editCell ()
	Get a pointer, possibly null, to the current cell being edited.
bool	fieldEditable (CursorInfo const &cur) const
	Determine if the specified table cursor cell is editable or not.
bool	fieldEditable (size_t tableRow, size_t tableCol) const
	Determine if a specified row and column is and editable column.
void	findFirst (CursorWindow::viewport *vp)
	Prompt the user for find string parameter and search for that string from the current edit point.
virtual bool	findNext (CursorWindow::viewport *vp, bool first)
	Search for the current search_text_ from the current cell to the end of the table. Update the screen to reflect the new cursor position.
void	forceRelayout ()
	mark the table layout for recomputation at some later point in time
void	insertRowAbove (CursorWindow::viewport *vp, RowInfo const &info)
	Insert new row above the current row.
void	insertRowBelow (CursorWindow::viewport *vp, RowInfo const &info)
	Insert new row below the current row.
virtual void	paintField (CursorWindow::viewport *vp, size_t vpRow, size_t vpCol, CellInfo const *cell, size_t cellRow, size_t vpColumns, bool editCursor)
	Called by paintCursor to draw the text of the field on the screen. This function handles clipping and truncaton of text that is too long in coordination with fieldEditColumn_.
void	positionTextInputPointer (CursorWindow::viewport *vp)
void	setTextInputPointer (size_t vpRow, size_t vpCol)
	Set the screen location where text cursor goes.
void	snatchEdit (CursorWindow::viewport *vp, FileName const &directory)
	Given the current cursor position within the current cell, snatch a filename / line number pair out of the text and open an edit session on that file/line.
void	terminateInput ()
	If the current cell has been edited, finish the editing process.
Static Protected Member Functions
static bool	isTableEditKey (CursorWindow::input_event const *e)
	Returns true if the specified event is an "edit" key.
Protected Attributes
std::vector< ColumnInfo >	cols_
std::vector< size_t >	colWidths_
int	delimiter_
bool	is_regex_
	If true, use regular expression searches.
bool	keyKludge_
LayoutType	layout_
ViewerManager *	manager_
bool	match_words_
	If true, use word searches.
bool	mixed_case_
	If true, use case insensitive searches.
size_t	pageHeight_
size_t	pageWidth_
std::vector< RowInfo >	rows_
std::string	search_text_
	Text to search for ////////////////////////////////////////////////////////////////////////////////////.
Private Member Functions
virtual bool	handle_event (CursorWindow::input_event const *e, CursorWindow::viewport *vp)
	Handle keystrokes and other events by superceding the the behavior of the TableViewer.
virtual void	help ()
	Display help about this application.
bool	okToQuit (CursorWindow::viewport *vp)
	Return true if it is ok to exit.
void	saveTo (std::string const &filename)
	Write the table to the specified file.
virtual void	setCursorInfo (CursorWindow::viewport *vp, size_t worldRow, size_t worldCol, bool displayed)
	Superseed of base class version only for the purpose of detecting field changes so that edit sessions on fields can be terminated.
Private Attributes
std::string	fileError_
std::string	filename_

---

Detailed Description

A Comma Separated Values file viewer.

This class reads and displays comma separated values files. The user is allowed to change the contents of the file and save those changes or write them to a different file.

Definition at line 33 of file csvviewer.h.

---

Member Typedef Documentation

typedef CursorWindow::input_event input_event [inherited]

typename alias

Definition at line 192 of file viewer.h.

typedef std::vector< std::vector< CellInfo > > LayoutType [inherited]

Definition at line 624 of file tableviewer.h.

typedef std::list<std::string> paste_buffer_type [inherited]

The data type of the paste buffer.

Definition at line 194 of file viewer.h.

typedef CursorWindow::row_col row_col [inherited]

typename alias

Definition at line 191 of file viewer.h.

typedef CursorWindow::viewport viewport [inherited]

Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

typename alias

Definition at line 190 of file viewer.h.

---

Member Enumeration Documentation

enum cmd_constant [inherited]

values that will be passed to the function call operator method.

Enumerator:

activate	means you have been activated
deactivate	some other viewport has taken focus
resize	only the size has changed

Definition at line 793 of file cursorwindow.h.

---

Constructor & Destructor Documentation

CsvViewer	(	ViewerManager *	vm,
		std::string const &	filename,
		int	delimChar = ','
	)

Construct a CsvViewer and open its file and read it into memory. The lines in the file are assumed to be delimited by the specified delimiter character. This constructor assumes that the first line of the file contains the names of the columns rather than the data for a row of text. The column headers must be delimited as well.

Parameters:

	vm	The viewermanager controlling this viewer.
	filename	defines the file that contains the comma separated values.
	delimChar	defines the character that delimits the values -- the default is of course comma but other characters can be used -- tab, "|" or others as needed.

Definition at line 49 of file csvviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

~CsvViewer

(

)

[virtual]

Definition at line 44 of file csvviewer.cxx.

---

Member Function Documentation

bool active

(

)

const [inherited]

Return the current "is window active" flag.

A given window is active if it has text focus, otherwise it is not.

Definition at line 615 of file tableviewer.h.

Here is the caller graph for this function:

void addColumnData

(

std::string const &

text

)

[inherited]

Definition at line 387 of file tableviewer.h.

Here is the call graph for this function:

Here is the caller graph for this function:

void addColumnHeader	(	std::string const &	title,
		size_t	width,
		FieldAttributes const &	a,
		bool	border
	)			[inherited]

Add a column to the column header table.

Parameters:

	title	defines the title for the row
	width	defines the number of screen columns to for this world column
	a	defines the field attributes
	border	defines the left border drawing option

Definition at line 371 of file tableviewer.h.

void addColumnHeader	(	std::string const &	title,
		size_t	width,
		bool	border
	)			[inherited]

Add a column to the column header table.

Parameters:

	title	defines the title for the row
	width	defines the number of screen columns to for this world column
	border	defines the left border drawing option

Definition at line 360 of file tableviewer.h.

Here is the caller graph for this function:

void addRow	(	std::string const &	title,
		size_t	height,
		bool	bottomBorder,
		bool	bold = false,
		bool	editable = true,
		bool	executable = true
	)			[inherited]

Definition at line 407 of file tableviewer.h.

Here is the caller graph for this function:

Viewer * app	(	ViewerManager *	vm,
		std::string &	fullname
	)			[static]

Application "hook" function for the CsvViewer class. Use it as a parameter to add_app, like this:

       vm.add_app(CsvViewer::app, "CsvViewer");

Definition at line 327 of file csvviewer.cxx.

Here is the call graph for this function:

std::string const & application_name

(

)

const [virtual]

Return the application name.

Reimplemented from TableViewer.

Definition at line 313 of file csvviewer.cxx.

TableViewer::CellInfo * cellInfo	(	size_t	row,
		size_t	col
	)			[inherited]

return a null or a modifiable pointer to the specified cell information.

Parameters:

	row	defines the zero based row number of interest
	col	defines the zero based column number of interest

Returns:

a modifiable pointer to the desired cell or null if the cell does not exist.

Definition at line 551 of file tableviewer.cxx.

Here is the call graph for this function:

TableViewer::CellInfo const * cellInfo	(	size_t	row,
		size_t	col
	)			const [inherited]

return a null or a const pointer to the specified cell information.

Parameters:

	row	defines the zero based row number of interest
	col	defines the zero based column number of interest

Returns:

a const pointer to the desired cell or null if the cell does not exist.

Definition at line 543 of file tableviewer.cxx.

Here is the caller graph for this function:

void checkLayoutRecompute

(

)

[protected, inherited]

Definition at line 741 of file tableviewer.h.

Here is the call graph for this function:

Here is the caller graph for this function:

void clear

(

)

[inherited]

Discard all rows and columns.

Definition at line 1151 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

size_t cols

(

)

const [inherited]

return count of table columns

Definition at line 254 of file tableviewer.h.

Here is the caller graph for this function:

size_t columnWidth

(

size_t

column

)

const [inherited]

Consult the layout_ and the cols_ tables to determine with maximum of the column header and the widest cell in that column. Does not include gutters.

Definition at line 510 of file tableviewer.cxx.

Here is the caller graph for this function:

void commitPasteBuffer

(

)

const [inherited]

write the paste buffer to the os clipboard.

Definition at line 625 of file viewer.cxx.

Here is the caller graph for this function:

CursorInfo cursorInfo

(

)

const [inherited]

Return the current cursor information.

Definition at line 491 of file tableviewer.h.

Here is the caller graph for this function:

void deleteRow

(

CursorWindow::viewport *

vp

)

[protected, inherited]

Erase the current row.

Parameters:

vp

the viewport to draw in -- though none is none

Definition at line 1242 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

std::string description

(

)

const [virtual]

Return a description of the application.

Reimplemented from TableViewer.

Definition at line 321 of file csvviewer.cxx.

TableViewer::CellInfo * editCell

(

)

[protected, inherited]

Get a pointer, possibly null, to the current cell being edited.

Returns:

a pointer cell information for the current cursor position.

If the return value is null, then table is empty.

Definition at line 59 of file tableeditor.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

std::string const& error

(

)

const

Returns the most recent file i/o error.

Definition at line 76 of file csvviewer.h.

bool fetchAllLines

(

std::list< std::string > &

output

)

[virtual, inherited]

An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.

Warning:

This is an optional feature, many viewers do not support it.

Parameters:

[out]

output

The location to store all the lines from this viewer.

Returns:

true to indicate that the data was extracted and false to indicate that this viewer does not support this feature.

Reimplemented in ListViewer.

Definition at line 705 of file viewer.cxx.

Here is the caller graph for this function:

void fetchPasteBuffer

(

)

[inherited]

read the paste buffer from the os clipboard

Definition at line 661 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool fieldEditable

(

CursorInfo const &

cur

)

const [protected, inherited]

Determine if the specified table cursor cell is editable or not.

Returns:

true if the table row and column, specified in cur refers to an editable location.

Parameters:

cur

The table cursor position (not screen, table)

Definition at line 164 of file tableeditor.h.

Here is the call graph for this function:

bool fieldEditable	(	size_t	tableRow,
		size_t	tableCol
	)			const [protected, inherited]

Determine if a specified row and column is and editable column.

Returns:

true if the specified row and column is editable.

Parameters:

	tableRow	-- the row within the table, has nothing to do with screen coordinates.
	tableCol	-- the column within the table, has nothing to do with screen coordinates.

Definition at line 143 of file tableeditor.h.

Here is the caller graph for this function:

void findFirst

(

CursorWindow::viewport *

vp

)

[protected, inherited]

Prompt the user for find string parameter and search for that string from the current edit point.

Definition at line 1257 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool findNext	(	CursorWindow::viewport *	vp,
		bool	first
	)			[protected, virtual, inherited]

Search for the current search_text_ from the current cell to the end of the table. Update the screen to reflect the new cursor position.

Parameters:

	vp	The viewport in which to draw
	first	True if the is first time this string has been used for the search (and thus the current cell should be searched).

Returns:

true to indicate that the search text was found and that the the screen has been updated.

Definition at line 1373 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void forceRelayout

(

)

[protected, inherited]

mark the table layout for recomputation at some later point in time

Definition at line 718 of file tableviewer.h.

Here is the caller graph for this function:

bool handle_event	(	CursorWindow::input_event const *	e,
		CursorWindow::viewport *	vp
	)			[private, virtual]

Handle keystrokes and other events by superceding the the behavior of the TableViewer.

Reimplemented from TableEditor.

Definition at line 164 of file csvviewer.cxx.

Here is the call graph for this function:

void help

(

)

[private, virtual]

Display help about this application.

Reimplemented from TableViewer.

Definition at line 378 of file csvviewer.cxx.

Here is the call graph for this function:

void hideCursor

(

CursorWindow::viewport *

vp

)

[inherited]

If cursor is visible, repaint it to remove its highlighting. Also, terminate any edit state operations (if any).

Definition at line 667 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void insertRowAbove	(	CursorWindow::viewport *	vp,
		RowInfo const &	info
	)			[protected, inherited]

Insert new row above the current row.

Parameters:

	vp	the viewport to draw in
	info	the title of the current row

Definition at line 1172 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void insertRowBelow	(	CursorWindow::viewport *	vp,
		RowInfo const &	info
	)			[protected, inherited]

Insert new row below the current row.

Parameters:

	vp	the viewport to draw in
	info	the title of the current row

Definition at line 1194 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool is_dirty

(

)

const [virtual, inherited]

Return true if the application has modifications.

Reimplemented from Viewer.

Definition at line 441 of file tableviewer.cxx.

Here is the caller graph for this function:

bool isTableEditKey

(

CursorWindow::input_event const *

e

)

[static, protected, inherited]

Returns true if the specified event is an "edit" key.

Parameters:

e

a pointer to an input event that should treated as if it were printable character or delete character, that sort of thing.

Definition at line 704 of file tableeditor.cxx.

Here is the caller graph for this function:

size_t longestRowTitle

(

)

const [inherited]

returns the number of chars in longest title

Definition at line 449 of file tableviewer.cxx.

Here is the caller graph for this function:

ViewerManager* manager

(

)

[inherited]

Definition at line 126 of file viewer.h.

Here is the caller graph for this function:

bool mixed_case

(

)

const [inherited]

Return the state of the mixed-case-find flag.

Definition at line 621 of file tableviewer.h.

Here is the caller graph for this function:

void moveDown

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor down one row. Normally bound to the down arrow key.

Definition at line 896 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveLeft

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor left one column. Normally bound to the left arrow key.

Definition at line 930 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveRight

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor right one column. Normally bound to the right arrow key.

Definition at line 954 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void moveUp

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor up one row. Normally bound to the up arrow key.

Definition at line 869 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool ok

(

)

const

Return true if no file read errors have occurred. See error() for details of any error.

Definition at line 72 of file csvviewer.h.

bool okToQuit

(

CursorWindow::viewport *

vp

)

[private]

Return true if it is ok to exit.

Definition at line 128 of file csvviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void operator()	(	CursorWindow::viewport *	vp,
		int	cmd
	)			[virtual, inherited]

Handle screen repaint commands.

Implements Viewer.

Definition at line 63 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

size_t originCol

(

)

const [inherited]

top left corner column

Definition at line 257 of file tableviewer.h.

Here is the caller graph for this function:

size_t originRow

(

)

const [inherited]

top left corner row

Definition at line 256 of file tableviewer.h.

Here is the caller graph for this function:

void pageBottom

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor to the last valid rows, and keep the column the same.

Normally bound to the control B key.

Definition at line 1121 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageDown

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor down one page. Keep the column the same.

Normally bound to the PageDown or Next key.

Definition at line 1001 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageEnd

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor to maxrow,maxcol Keep the column the same.

Normally bound to the end key

Definition at line 1110 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageHome

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor to 0,0.

Normally bound to the Home key

Definition at line 1101 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageLeft

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor left one page. Keep the column the same.

Normally bound to the shift-Tab key.

Definition at line 1069 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageRight

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor right one page. Keep the column the same.

Normally bound to the tab key.

Definition at line 1034 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageTop

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor to the first row in the table. keep the column the same.

Normally bound to the control B key.

Definition at line 1138 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void pageUp

(

CursorWindow::viewport *

vp

)

[inherited]

Move the cursor up one page. Keep the column the same.

Normally bound to the PageUp or Prior key.

Definition at line 980 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintCell	(	CursorWindow::viewport *	vp,
		size_t	vpRow,
		size_t	vpCol,
		size_t	tbRow,
		size_t	tbCol,
		bool	highlight = false,
		bool	editCursor = true
	)			[inherited]

Paint the specified cell at the specified viewport location. No validity checking is done. The most recently painted viewport is used.

Parameters:

	vp	the viewport to draw in
	vpRow	the viewport row
	vpCol	the column
	tbRow	table row
	tbCol	the table column
	highlight	flag indicating highlighted display
	editCursor	flag indicating the cursor should be left in edit poisiton

Definition at line 785 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintCursor

(

CursorWindow::viewport *

vp

)

[virtual, inherited]

If the cursor is marked for display, draw it on the screen.

The function is virtual so that derived classes can hook into the repaint functionality so they can position the edit cursor.

Parameters:

vp

is the viewport to positiont he cursor into

Definition at line 684 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void paintField	(	CursorWindow::viewport *	vp,
		size_t	vpRow,
		size_t	vpCol,
		TableViewer::CellInfo const *	cell,
		size_t	cellRow,
		size_t	vpColumns,
		bool	editCursor
	)			[protected, virtual, inherited]

Called by paintCursor to draw the text of the field on the screen. This function handles clipping and truncaton of text that is too long in coordination with fieldEditColumn_.

Parameters:

	vp	the viewport into which to draw the field
	vpRow	the row within the viewport to paint the field
	vpCol	the column within the viewport to start the painting
	cell	the table cell to paint
	vpColumns	the number columns the field should take up
	editCursor	indicates that the cursor should be left in the field edit position (or not).

If editCursor is false, the cursor will be left at the end of the the field.

See also:

TableViewer::paintField for an explanation of the parameters and the environment under which this function is called.

Note:

This function leaves the cursor in first column of the the field, not at the end! PaintCell calls this function and this fact needs to be understood when writing paint handlers.

Reimplemented from TableViewer.

Definition at line 589 of file tableeditor.cxx.

Here is the call graph for this function:

Viewer::paste_buffer_type * paste_buffer

(

)

[inherited]

Get a pointer to the viewer manager's paste buffer.

Definition at line 601 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void positionTextInputPointer

(

CursorWindow::viewport *

vp

)

[protected, inherited]

Definition at line 1164 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void repaintTitle

(

CursorWindow::viewport *

vp

)

[virtual, inherited]

Repaint the title (presumably after it has changed).

Parameters:

vp

The viewport where this table is drawn.

By default, this function prints the application name, but derived classes may wish to superseed this behavior.

Reimplemented in ScriptTableViewer.

Definition at line 48 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

RowInfo const& rowInfo

(

size_t

row

)

const [inherited]

get a copy of a specified row titles, etc.

Parameters:

row

The row to modify

Returns:

The specified row's information.

Definition at line 414 of file tableviewer.h.

Here is the caller graph for this function:

size_t rows

(

)

const [inherited]

return count of table rows

Definition at line 253 of file tableviewer.h.

Here is the caller graph for this function:

void saveTo

(

std::string const &

filename

)

[private]

Write the table to the specified file.

Definition at line 231 of file csvviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void set_data_dirty

(

bool

f

)

[inherited]

Set the 'unsaved modifications' flag.

Parameters:

f

defines the status of the dirty flag.

See the function is_dirty().

Definition at line 608 of file tableviewer.h.

Here is the caller graph for this function:

virtual void set_row_col_hint	(	size_t	line,
		size_t	column,
		bool	repaint = false
	)			[virtual, inherited]

The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.

Again, obedience to this function is entirely optional and most viewers will ignore it.

The line and column numbers are 0 base! Contrary to normal user's expectations, so account for this in any input calculations you make.

Definition at line 202 of file viewer.h.

Here is the caller graph for this function:

void setColInfo	(	size_t	col,
		std::string const &	title,
		size_t	width,
		bool	border,
		bool	bold,
		bool	edit
	)			[inherited]

Set the column header information.

Parameters:

	col	defines the col number of interest (world col, not screen col)
	title	defines the title for the row
	width	defines the number of screen columns to for this world column
	border	defines the left border drawing option
	bold	defines the bold display attribute for this column
	edit	defines the editable flag for this colum

Definition at line 339 of file tableviewer.h.

void setColInfo	(	size_t	col,
		std::string const &	title,
		size_t	width,
		bool	border
	)			[inherited]

Set the column header information.

Parameters:

	col	defines the col number of interest (world col, not screen col)
	title	defines the title for the row
	width	defines the number of screen columns to for this world column
	border	defines the left border drawing option

Definition at line 322 of file tableviewer.h.

Here is the caller graph for this function:

void setCursorInfo	(	CursorWindow::viewport *	vp,
		CursorInfo const &	i
	)			[inherited]

Set the cursor information given a CursorInfo structure.

Definition at line 495 of file tableviewer.h.

Here is the call graph for this function:

void setCursorInfo	(	CursorWindow::viewport *	vp,
		size_t	worldRow,
		size_t	worldCol,
		bool	displayed
	)			[private, virtual]

Superseed of base class version only for the purpose of detecting field changes so that edit sessions on fields can be terminated.

See also:

TableViewer::setCursorInfo

Reimplemented from TableEditor.

Definition at line 217 of file csvviewer.cxx.

Here is the call graph for this function:

void setDisplayTitles

(

bool

flag

)

[inherited]

Set the flag that controls the permanancy of the displaying of the row and column titles.

Parameters:

flag

if true, means that the titles should always be displayed.

Definition at line 259 of file tableviewer.h.

void setOrigin	(	size_t	row,
		size_t	col
	)			[inherited]

Set the upper left corner column in the world world of the layout_ no the screen coordinate world.

Parameters:

	row	is the row in the virtual world
	col	is the column in hte virtual world

Definition at line 443 of file tableviewer.h.

Here is the caller graph for this function:

void setRowInfo	(	size_t	row,
		RowInfo const &	r
	)			[inherited]

Set the titles and other row specific information givin a row.

Parameters:

	row	The row to modify
	r	The RowInfo to change

Definition at line 420 of file tableviewer.h.

void setRowInfo	(	size_t	row,
		std::string const &	title,
		size_t	height,
		bool	border,
		bool	bold,
		bool	edit
	)			[inherited]

Set the row header information.

Parameters:

	row	defines the row number of interest (world row, not screen row)
	title	defines the title for the row
	height	defines the number of screen rows to reserve vertically for "row"
	border	defines the bottom border drawing option
	bold	defines the bold drawing flag for the row
	edit	defines the editable flag for this row

Definition at line 300 of file tableviewer.h.

void setRowInfo	(	size_t	row,
		std::string const &	title,
		size_t	height,
		bool	border
	)			[inherited]

Set the row header information.

Parameters:

	row	defines the row number of interest (world row, not screen row)
	title	defines the title for the row
	height	defines the number of screen rows to reserve vertically for "row"
	border	defines the bottom border drawing option

Definition at line 283 of file tableviewer.h.

Here is the caller graph for this function:

void setRowsAndColumns	(	size_t	rows,
		size_t	cols
	)			[inherited]

Set the maximum number of rows and columns in the layout. Adding or deleting as necessary to make it happen.

Parameters:

	rows	is the exact number of rows to establish
	cols	is the exact number of cols to establish.

Definition at line 492 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void setTextInputPointer	(	size_t	vpRow,
		size_t	vpCol
	)			[protected, inherited]

Set the screen location where text cursor goes.

Parameters:

	vpRow	is the viewport relative row
	vpCol	is the viewport relative column

Definition at line 707 of file tableviewer.h.

Here is the caller graph for this function:

void showCursor

(

CursorWindow::viewport *

vp

)

[inherited]

If the cursor is not already displayed, repaint it to indicate highlighting for edit.

Definition at line 676 of file tableviewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void snatchEdit	(	CursorWindow::viewport *	vp,
		FileName const &	directory
	)			[protected, inherited]

Given the current cursor position within the current cell, snatch a filename / line number pair out of the text and open an edit session on that file/line.

Parameters:

[in]	vp	The viewport to draw in.
[out]	directory	The directory that the file name, extracted from the cell text, is meant to be found relative to. WARNING: The directory name must have a trailing separator (/ or \).

Definition at line 462 of file tableeditor.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void terminateInput

(

)

[protected, inherited]

If the current cell has been edited, finish the editing process.

Definition at line 582 of file tableeditor.cxx.

Here is the caller graph for this function:

void triggerLayoutRecompute

(

)

[inherited]

implement a copy constructor!

Called by field editing functions to inform the table repaint mechanism, operator()(), that the column sizes need to be recomputed.

Definition at line 63 of file tableviewer.h.

Here is the caller graph for this function:

---

Member Data Documentation

std::vector<ColumnInfo> cols_ [protected, inherited]

Definition at line 666 of file tableviewer.h.

std::vector<size_t> colWidths_ [protected, inherited]

Definition at line 660 of file tableviewer.h.

int delimiter_ [protected, inherited]

Definition at line 76 of file tableeditor.h.

std::string fileError_ [private]

Definition at line 44 of file csvviewer.h.

std::string filename_ [private]

Definition at line 43 of file csvviewer.h.

bool is_regex_ [protected, inherited]

If true, use regular expression searches.

Definition at line 672 of file tableviewer.h.

bool keyKludge_ [protected, inherited]

Reimplemented in ScriptTableViewer.

Definition at line 77 of file tableeditor.h.

LayoutType layout_ [protected, inherited]

Definition at line 663 of file tableviewer.h.

ViewerManager* manager_ [protected, inherited]

Definition at line 117 of file viewer.h.

bool match_words_ [protected, inherited]

If true, use word searches.

Definition at line 673 of file tableviewer.h.

bool mixed_case_ [protected, inherited]

If true, use case insensitive searches.

Definition at line 671 of file tableviewer.h.

size_t pageHeight_ [protected, inherited]

Definition at line 658 of file tableviewer.h.

size_t pageWidth_ [protected, inherited]

Definition at line 657 of file tableviewer.h.

std::vector<RowInfo> rows_ [protected, inherited]

Definition at line 665 of file tableviewer.h.

std::string search_text_ [protected, inherited]

Text to search for ////////////////////////////////////////////////////////////////////////////////////.

Definition at line 674 of file tableviewer.h.

---

The documentation for this class was generated from the following files:

• include/cxxtls/csvviewer.h
• lib/csvviewer.cxx
