FTPviewer Class Reference

An FTPviewer is a Viewer meant for displaying and editing files and directories exported by an ftp server. It a large extent, it looks and feels like a directory viewer -- except that the files and directories being displayed are on a remote system. The ftp viewer also maintains a reference to a 'current directory' on the local machine where files on the remote machine will be stored when you 'get' a file. Analogously, files in the local directory may be 'put' to the remote system. More...

#include <ftpviewer.h>

Inheritance diagram for FTPviewer:
Inheritance graph
[legend]
Collaboration diagram for FTPviewer:
Collaboration graph
[legend]

List of all members.

Classes

struct  Impl

Public Types

enum  cmd_constant {
  activate,
  deactivate,
  resize
}


values that will be passed to the function call operator method.

More...
typedef CursorWindow::input_event input_event
 typename alias
typedef std::list< std::string > paste_buffer_type
 The data type of the paste buffer.
typedef CursorWindow::row_col row_col
 typename alias
typedef CursorWindow::viewport viewport
 Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

Public Member Functions

std::string const & application_name () const
 The name to prompt the user with in the ViewerManager::appChooser menu.
void commitPasteBuffer () const
 write the paste buffer to the os clipboard.
std::string description () const
 Return the name of the application to use when describing this viewer in the ViewerManager::appChooser or in the ViewerManager::ViewerSelector.
virtual bool fetchAllLines (std::list< std::string > &output)
 An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.
void fetchPasteBuffer ()
 read the paste buffer from the os clipboard
 FTPviewer (ViewerManager *vm, FileName const &local_directory, std::string const &remote_host, std::string const &userid, std::string const &password, std::string const &remote_directory=std::string())
virtual bool handle_event (CursorWindow::input_event const *event, CursorWindow::viewport *viewport)
 Handle screen repaint commands.
virtual void help ()
 Handle input events.
virtual bool is_dirty () const
ViewerManagermanager ()
virtual void operator() (CursorWindow::viewport *vp, int cmd)
 Handle screen repaint commands.
paste_buffer_typepaste_buffer ()
 Get a pointer to the viewer manager's paste buffer.
virtual void set_row_col_hint (size_t line, size_t column, bool repaint=false)
 The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.
 ~FTPviewer ()

Static Public Member Functions

static Viewerapp (ViewerManager *vm, std::string &fullname)

Public Attributes

std::auto_ptr< Implimpl_
 implemenation data not needing to be visible to users.

Static Public Attributes

static std::string app_name
 Application "hook" function for the DirectoryViewer class. Use it as a parameter to add_app, like this:

Protected Attributes

ViewerManagermanager_

Detailed Description

An FTPviewer is a Viewer meant for displaying and editing files and directories exported by an ftp server. It a large extent, it looks and feels like a directory viewer -- except that the files and directories being displayed are on a remote system. The ftp viewer also maintains a reference to a 'current directory' on the local machine where files on the remote machine will be stored when you 'get' a file. Analogously, files in the local directory may be 'put' to the remote system.

When creating an FTPviewer, you must supply:

You may only get, put, and navigate directories on the remote machine.

To create an ftp viewer, use the static member function,

     FTPviewer::app(ViewerManager*, std::string local_directory)

It will prompt the user for the needed information. You must supply the local directory as a parameter.

Definition at line 43 of file ftpviewer.h.


Member Typedef Documentation

typename alias

Definition at line 192 of file viewer.h.

typedef std::list<std::string> paste_buffer_type [inherited]

The data type of the paste buffer.

Definition at line 194 of file viewer.h.

typedef CursorWindow::row_col row_col [inherited]

typename alias

Definition at line 191 of file viewer.h.

typedef CursorWindow::viewport viewport [inherited]

Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

typename alias

Definition at line 190 of file viewer.h.


Member Enumeration Documentation

enum cmd_constant [inherited]

values that will be passed to the function call operator method.

Enumerator:
activate

means you have been activated

deactivate

some other viewport has taken focus

resize

only the size has changed

Definition at line 793 of file cursorwindow.h.


Constructor & Destructor Documentation

FTPviewer ( ViewerManager vm,
FileName const &  local_directory,
std::string const &  remote_host,
std::string const &  userid,
std::string const &  password,
std::string const &  remote_directory = std::string()
)

Definition at line 138 of file ftpviewer.cxx.

Here is the caller graph for this function:

~FTPviewer (  )

Definition at line 167 of file ftpviewer.cxx.


Member Function Documentation

Viewer * app ( ViewerManager vm,
std::string &  fullname
) [static]

Definition at line 190 of file ftpviewer.cxx.

Here is the call graph for this function:

std::string const& application_name (  )  const [virtual]

The name to prompt the user with in the ViewerManager::appChooser menu.

Implements Viewer.

Definition at line 124 of file ftpviewer.h.

void commitPasteBuffer (  )  const [inherited]

write the paste buffer to the os clipboard.

Definition at line 625 of file viewer.cxx.

Here is the caller graph for this function:

string description (  )  const [virtual]

Return the name of the application to use when describing this viewer in the ViewerManager::appChooser or in the ViewerManager::ViewerSelector.

Implements Viewer.

Definition at line 182 of file ftpviewer.cxx.

bool fetchAllLines ( std::list< std::string > &  output  )  [virtual, inherited]

An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.

Warning:
This is an optional feature, many viewers do not support it.
Parameters:
[out] output The location to store all the lines from this viewer.
Returns:
true to indicate that the data was extracted and false to indicate that this viewer does not support this feature.

Reimplemented in ListViewer.

Definition at line 705 of file viewer.cxx.

Here is the caller graph for this function:

void fetchPasteBuffer (  )  [inherited]

read the paste buffer from the os clipboard

Definition at line 661 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool handle_event ( CursorWindow::input_event const *  event,
CursorWindow::viewport viewport
) [virtual]

Handle screen repaint commands.

Parameters:
vp
cmd

Implements Viewer.

Definition at line 118 of file ftpviewer.cxx.

void help (  )  [virtual]

Handle input events.

Parameters:
event
viewport Present the user with help information that is specific to this viewer's operation and contains information about system keep bindings, etc.

Reimplemented from Viewer.

Definition at line 126 of file ftpviewer.cxx.

bool is_dirty (  )  const [virtual, inherited]

Reimplemented in TableViewer.

Definition at line 611 of file viewer.cxx.

Here is the caller graph for this function:

ViewerManager* manager (  )  [inherited]

Definition at line 126 of file viewer.h.

Here is the caller graph for this function:

void operator() ( CursorWindow::viewport vp,
int  cmd
) [virtual]

Handle screen repaint commands.

Note:
The vp parameter gets deleted regularly, don't save it!

Implements Viewer.

Definition at line 108 of file ftpviewer.cxx.

Viewer::paste_buffer_type * paste_buffer (  )  [inherited]

Get a pointer to the viewer manager's paste buffer.

Definition at line 601 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void set_row_col_hint ( size_t  line,
size_t  column,
bool  repaint = false
) [virtual, inherited]

The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.

Again, obedience to this function is entirely optional and most viewers will ignore it.

The line and column numbers are 0 base! Contrary to normal user's expectations, so account for this in any input calculations you make.

Definition at line 202 of file viewer.h.

Here is the caller graph for this function:


Member Data Documentation

string app_name [static]

Application "hook" function for the DirectoryViewer class. Use it as a parameter to add_app, like this:

        vm.add_app(DirectoryViewer::app, "DirectoryViewer");

Definition at line 119 of file ftpviewer.h.

std::auto_ptr<Impl> impl_

implemenation data not needing to be visible to users.

Pointer to the implementation data

Definition at line 75 of file ftpviewer.h.

ViewerManager* manager_ [protected, inherited]

Definition at line 117 of file viewer.h.


The documentation for this class was generated from the following files:
