ViewerSelector Class Reference

This viewer allows the user to select from any extant viewer rather than creating a new viewer as does the appChooser class below. More...

Inheritance diagram for ViewerSelector:

[legend]

Collaboration diagram for ViewerSelector:

[legend]

List of all members.

Public Types
enum	cmd_constant { activate, deactivate, resize }
	values that will be passed to the function call operator method. More...
typedef CursorWindow::input_event	input_event
	typename alias
typedef std::list< std::string >	paste_buffer_type
	The data type of the paste buffer.
typedef CursorWindow::row_col	row_col
	typename alias
typedef CursorWindow::viewport	viewport
	Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.
Public Member Functions
string const &	application_name () const
	Return a const references to a string which defines the name of the application being implemented in the viewer. This function must always return the same address and the string at that address must never change;.
void	commitPasteBuffer () const
	write the paste buffer to the os clipboard.
string	description () const
	Get a description of this viewer. Typically, this just returns the name of the directory or the name of the file the viewer is being applied to. However, with FTP viewers, POP3 viewers, etc this may not refer to any real file.
virtual bool	fetchAllLines (std::list< std::string > &output)
	An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.
void	fetchPasteBuffer ()
	read the paste buffer from the os clipboard
bool	handle_event (CursorWindow::input_event const e, CursorWindow::viewport vp)
	Handle screen repaint commands.
virtual void	help ()
	Present the user with help information that is specific to this viewer's operation and contains information about system keep bindings, etc. Note that there is a default implementation of this function, but it should be overridden.
virtual bool	is_dirty () const
ViewerManager *	manager ()
void	operator() (CursorWindow::viewport *vp, int cmd)
	Handle screen repaint commands.
void	output_row_text (CursorWindow::viewport *vp, int i)
paste_buffer_type *	paste_buffer ()
	Get a pointer to the viewer manager's paste buffer.
void	repaint (CursorWindow::viewport *vp)
virtual void	set_row_col_hint (size_t line, size_t column, bool repaint=false)
	The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.
	ViewerSelector (ViewerManager *m)
Public Attributes
bool	active_
	first display of viewport info
size_t	cur_row_
size_t	display_top_
	row where cursor is sitting
int	first_row_
	row at top of viewport
Static Public Attributes
static string	app_name
Protected Attributes
ViewerManager *	manager_

Detailed Description

This viewer allows the user to select from any extant viewer rather than creating a new viewer as does the appChooser class below.

Definition at line 66 of file viewermanager.cxx.

Member Typedef Documentation

typedef CursorWindow::input_event input_event [inherited]

typename alias

Definition at line 192 of file viewer.h.

typedef std::list<std::string> paste_buffer_type [inherited]

The data type of the paste buffer.

Definition at line 194 of file viewer.h.

typedef CursorWindow::row_col row_col [inherited]

typename alias

Definition at line 191 of file viewer.h.

typedef CursorWindow::viewport viewport [inherited]

Returns true if there are unsaved edit changes in this viewer. the default return value is false. Override this function if your viewer has the ability to have unsaved edit changes -- most don't.

typename alias

Definition at line 190 of file viewer.h.

Member Enumeration Documentation

enum cmd_constant [inherited]

values that will be passed to the function call operator method.

Enumerator:

activate	means you have been activated
deactivate	some other viewport has taken focus
resize	only the size has changed

Definition at line 793 of file cursorwindow.h.

Constructor & Destructor Documentation

ViewerSelector ( ViewerManager * m )

Definition at line 81 of file viewermanager.cxx.

Member Function Documentation

string const& application_name ( ) const [virtual]

Return a const references to a string which defines the name of the application being implemented in the viewer. This function must always return the same address and the string at that address must never change;.

Implements Viewer.

Definition at line 100 of file viewermanager.cxx.

void commitPasteBuffer ( ) const [inherited]

write the paste buffer to the os clipboard.

Definition at line 625 of file viewer.cxx.

Here is the caller graph for this function:

string description ( ) const [virtual]

Get a description of this viewer. Typically, this just returns the name of the directory or the name of the file the viewer is being applied to. However, with FTP viewers, POP3 viewers, etc this may not refer to any real file.

Implements Viewer.

Definition at line 132 of file viewermanager.cxx.

bool fetchAllLines ( std::list< std::string > & output ) [virtual, inherited]

An optional method that fetches all the lines in this viewer object into a caller supplied list of strings.

Warning:: This is an optional feature, many viewers do not support it.

Parameters:

[out] output The location to store all the lines from this viewer.

Returns:: true to indicate that the data was extracted and false to indicate that this viewer does not support this feature.

Reimplemented in ListViewer.

Definition at line 705 of file viewer.cxx.

Here is the caller graph for this function:

void fetchPasteBuffer ( ) [inherited]

read the paste buffer from the os clipboard

Definition at line 661 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

bool handle_event	(	CursorWindow::input_event const *	e,
		CursorWindow::viewport *	vp
	)			`[virtual]`

Handle screen repaint commands.

Implements Viewer.

Definition at line 1288 of file viewermanager.cxx.

Here is the call graph for this function:

void help ( ) [virtual, inherited]

Present the user with help information that is specific to this viewer's operation and contains information about system keep bindings, etc. Note that there is a default implementation of this function, but it should be overridden.

Reimplemented in ListViewer, CsvViewer, TreeViewer, TableViewer, ScriptTableViewer, TextViewer, and FTPviewer.

Definition at line 583 of file viewer.cxx.

Here is the caller graph for this function:

bool is_dirty ( ) const [virtual, inherited]

Reimplemented in TableViewer.

Definition at line 611 of file viewer.cxx.

Here is the caller graph for this function:

ViewerManager* manager ( ) [inherited]

Definition at line 126 of file viewer.h.

Here is the caller graph for this function:

void operator()	(	CursorWindow::viewport *	vp,
		int	cmd
	)			`[virtual]`

Handle screen repaint commands.

Note:: The vp parameter gets deleted regularly, don't save it!

Implements Viewer.

Definition at line 1178 of file viewermanager.cxx.

Here is the call graph for this function:

void output_row_text	(	CursorWindow::viewport *	vp,
		int	i
	)

Definition at line 107 of file viewermanager.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

Viewer::paste_buffer_type * paste_buffer ( ) [inherited]

Get a pointer to the viewer manager's paste buffer.

Definition at line 601 of file viewer.cxx.

Here is the call graph for this function:

Here is the caller graph for this function:

void repaint ( CursorWindow::viewport * vp )

Definition at line 102 of file viewermanager.cxx.

Here is the caller graph for this function:

virtual void set_row_col_hint	(	size_t	line,
		size_t	column,
		bool	repaint = `false`
	)			`[virtual, inherited]`

The set_row_col_hint() method lets you specify the location where the cursor should be positioned. It is called a 'hint' because mistakes in the calling parameters are silently ignored. Also, obedience to the hint is optional. The 'repaint' parameter indicates that the screen should be immediately updated to reflect the change.

Again, obedience to this function is entirely optional and most viewers will ignore it.

The line and column numbers are 0 base! Contrary to normal user's expectations, so account for this in any input calculations you make.

Definition at line 202 of file viewer.h.

Here is the caller graph for this function:
